AWX701TX IR RF Remote Control Extender TX... - FCC ID NGVAWX701TX

FCC ID NGVAWX701TX

Test Setup Photos

IR RF Remote Control Extender TX

by Airwave Technologies Inc

Document preview loads when visible.

Document Details

FCC IDNGVAWX701TX
Document ID317386
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document Title033H057FI A1-.j.T_AWX701TX_-Tx
ApplicantAirwave Technologies Inc
Equipment ClassIR RF Remote Control Extender TX
Product CodeAWX701TX
Application IDquDicEzB8pd599ve1OHBGw==
Application PurposeOriginal Equipment
Application Date2003-04-11
Frequency Range418 MHz
FRN0008778128
Test FirmDEKRA Testing and Certification Co., Ltd.
Certified ByGene Chang President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2003-04-11
Available2003-04-11
Created2003-04-11
Modified2003-04-11
Pages3
File TypeAdobe Acrobat PDF
File Size320886
File SHA-256d9f9e0dc5fddc907a8db10b65259b2014f68377b0dfc71d58fa17ee59a9c26aa
PDF Metadata Authorlydiatsai
PDF Metadata ProducerAcrobat Distiller 5.0 (Windows) lydiatsai
FCC.gov SourcesFCC.gov 317386
