FCC ID NI4TMLF15-3
Smart LF Oscillator
by Toyota Motor Corporation
Grantee Code: NI4 Product Code: TMLF153
Latest application date: 2015-12-10
Device Images
FCC ID Device Details
| FCC ID | NI4TMLF15-3 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | NI4 |
| Product Code | TMLF153 |
| Applicant Business | Toyota Motor Corporation 🇯🇵 |
| Related Domains |  mail.toyota.co.jp |
| Equipment Class | Smart LF Oscillator |
| Test Firm | UL Japan, Inc. Head office EMC Lab. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 0.134 MHz | Original Equipment | 2015-12-10 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-12-10 | PDF 62.3 KB |
| Internal Photo | Internal Photos | 2015-12-10 | PDF 482.7 KB |
| External Photo | External Photos | 2015-12-10 | PDF 441.4 KB |
| Label and Location | ID Label/Location Info | 2015-12-10 | PDF 65.7 KB |
| FCC Test Setup Photo_DCD | Test Setup Photos | 2015-12-10 | PDF 1.8 MB |
| FCC Test Report_DCD | Test Report | 2015-12-10 | PDF 210.8 KB |
| FCC Authorization Letter | Cover Letter(s) | 2015-12-10 | PDF 517.6 KB |
| FCC Request for Confidentiality Letter | Cover Letter(s) | 2015-12-10 | PDF 230.7 KB |
| (Confidential) Block Diagram Metadata only | Block Diagram | PDF 149.1 KB | |
| (Confidential) Schematics Metadata only | Schematics | PDF 320.1 KB | |
| (Confidential) Theory of Operation Metadata only | Operational Description | PDF 94.7 KB | |
| (Confidential) Parts List Metadata only | Parts List/Tune Up Info | PDF 221.6 KB |
Application Information
| Application ID | 0m41rKFeYDP/8cSed3f3Zg== |
|---|---|
| Final Action Date | 2015-12-10 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0011235801 |
| Model | TMLF15-3 |
| Frequency Range | 0.134 MHz |
| Equipment Class | DCD - Part 15 Low Power Transmitter Below 1705 kHz |
| Device Description | Smart LF Oscillator |
| Responsible Party | shinji suganuma, shinji_suganuma@mail.toyota.co.jp , 81-565-94-0902 |
| Agent | Yoshihisa Yoshihisa Yoshihisa, UL Japan, Inc., Yoshihisa.Maeda@ul.com  , 81-596-24-8999 |
| Technical Contact | Motoya Imura, UL Japan, Inc., Motoya.Imura@ul.com , 81-596-24-8999 |
| Test Firm | Tetsuya Hashimoto, UL Japan, Inc. Head office EMC Lab., Tetsuya.Hashimoto@jp.ul.com  , +81-596-24-8116 |
| TCB Email | emc.jp@ul.com |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 0m41rKFeYDP/8cSed3f3Zg== | 2015-12-10 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 0.134 MHz | 15C |
Grants
TCB Grant - Application 0m41rKFeYDP/8cSed3f3Zg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Japan, Inc. 4383-326 Asama-cho Ise-shi Mie, 5160021 Japan |
Date of Grant: 12/10/2015 Application Dated: 12/10/2015 |
| Toyota Motor Corporation |
| 1, Toyota-Cho |
| Toyota Aichi, 471-8572 Japan |
| Attention: shinji suganuma |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | NI4TMLF15-3 |
| Name of Grantee: | Toyota Motor Corporation |
| Equipment Class: | Part 15 Low Power Transmitter Below 1705 kHz |
| Notes: | Smart LF Oscillator |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 0.1342 - 0.1342 |
EAS Grant - Application 0m41rKFeYDP/8cSed3f3Zg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Toyota Motor Corporation 1, Toyota-Cho Toyota Aichi, 471-8572 Japan |
Date of Grant: 12/10/2015 Application Dated: 12/10/2015 |
| Attention: shinji suganuma |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | NI4TMLF15-3 |
| Name of Grantee: | Toyota Motor Corporation |
| Equipment Class: | Part 15 Low Power Transmitter Below 1705 kHz |
| Notes: | Smart LF Oscillator |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 0.1342 - 0.1342 |
| Mail To: |
