FCC ID NKR-DNXAH1
FCC ID NKR-DNXAH1 Users-Manual, NKR DNXAH1, NKR-DNXAH1, NKR-DNXAHI
Wistron NeWeb Corporation PCIe 802.11n WiFi module DNXAH1
An FCC ID is the product ID assigned by the FCC to identify wireless products in the market. The FCC chooses 3 or 5 character "Grantee" codes to identify the business that created the product.
For example, the grantee code for FCC ID: NKR-DNXAH1 is NKR. The remaining characters of the FCC ID, -DNXAH1, are often associated with the product model, but they can be random. These letters are chosen by the applicant.
In addition to the application, the FCC also publishes internal images, external images, user manuals, and test results for wireless devices. They can be under the "exhibits" tab below.
Purchase on Amazon:
PCIe 802.11n WiFi module
*Please Check Individual Documents for more images
- Application: PCIe 802.11n WiFi module
- Equipment Class: NII - Unlicensed National Information Infrastructure TX
- Short Link: fcc.id/NKR-DNXAH1
- Sources: FCC.gov | FCC.report
- Registered By: Wistron NeWeb Corporation - NKR (Taiwan)
| App # | Purpose | Date | Unique ID |
|---|---|---|---|
| 1 | Original Equipment | 2010-12-01 | 370sXD6qD5wYyJOQQtc2lQ== |
| 2 | Original Equipment | 2010-12-01 | u8y5CKMO4EXblW9yYzJvYw== |
| 3 | Class II Permissive Change | 2012-11-21 | LEJR1lgGqjz8/HWSNWQr8g== |
| 4 | Class II Permissive Change | 2012-11-21 | RRLt9fFjkV4cBt7R4sVqZw== |
| 5 | Class II Permissive Change | 2016-05-25 | cW4M6ySDP73Zi5GIUQW9dQ== |
Operating Frequencies
Device operates within approved frequencies overlapping with the following cellular bands: LTE 255,Unlicensed NII-3 DOWN | LTE 46,TD Unlicensed DOWN |
| Frequency Range | Power Output | Rule Parts | Grant Notes | App # |
|---|---|---|---|---|
2.412-2.462 GHz  | 732 mW | 15C | CC, MO | 3.1 |
| 2.412-2.462 GHz | 732 mW | 15C | CC, MO | 2.1 |
5.18-5.24 GHz  | 36 mW | 15E | CC, MO | 1.1 |
| 5.18-5.24 GHz | 36 mW | 15E | CC, MO | 4.1 |
| 5.18-5.24 GHz | 36 mW | 15E | 38, CC, MO | 5.1 |
| 5.745-5.825 GHz | 287 mW | 15C | CC, MO | 3.2 |
| 5.745-5.825 GHz | 287 mW | 15C | CC, MO | 2.2 |
| 5.745-5.825 GHz | 287 mW | 15E | 49, CC, MO | 5.2 |
Exhibits
Available Exhibits
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 5 | Users Manual.pdf | Users Manual Adobe Acrobat PDF (1119 kB) |
2016-05-25 2016-05-25 |
| 5 | Cover Letter (no power levels increased for U-NII-3).pdf | Cover Letter(s) Adobe Acrobat PDF (42 kB) |
2016-05-25 2016-05-25 |
| 5 | Cover Letter (no power levels increased for U-NII-1).pdf | Cover Letter(s) Adobe Acrobat PDF (41 kB) |
2016-05-25 2016-05-25 |
| 5 | Cover Letter (Hardware Antenna Attestation).pdf | Cover Letter(s) Adobe Acrobat PDF (41 kB) |
2016-05-25 2016-05-25 |
| 5 | Cover Letter (Description of Change).pdf | Cover Letter(s) Adobe Acrobat PDF (11 kB) |
2016-05-25 2016-05-25 |
| 5 | Cover Letter (Agent Authorization).pdf | Cover Letter(s) Adobe Acrobat PDF (49 kB) |
2016-05-25 2016-05-25 |
| 5 | Confidentiality Request.pdf | Cover Letter(s) Adobe Acrobat PDF (50 kB) |
2016-05-25 2016-05-25 |
| 4 | Manual | Users Manual Adobe Acrobat PDF (980 kB) |
2012-11-21 2012-11-21 |
| 4 | RF Exposure Info RFx | RF Exposure Info Adobe Acrobat PDF (52 kB) |
2012-11-21 2012-11-21 |
| 4 | Label and Location | ID Label/Location Info Adobe Acrobat PDF (210 kB) |
2012-11-21 2012-11-21 |
| 4 | L 452 | Internal Photos Adobe Acrobat PDF (1480 kB) |
2012-11-21 2012-11-21 |
| 4 | L 451 | Internal Photos Adobe Acrobat PDF (1817 kB) |
2012-11-21 2012-11-21 |
| 4 | L 452 | External Photos Adobe Acrobat PDF (1194 kB) |
2012-11-21 2012-11-21 |
| 4 | L 451 | External Photos Adobe Acrobat PDF (1217 kB) |
2012-11-21 2012-11-21 |
| 4 | DofC | Cover Letter(s) Adobe Acrobat PDF (71 kB) |
2012-11-21 2012-11-21 |
| 4 | L 452 Declaration | RF Exposure Info Adobe Acrobat PDF (46 kB) |
2012-11-21 2012-11-21 |
| 4 | Authorization | Cover Letter(s) Adobe Acrobat PDF (11 kB) |
2012-11-21 2012-11-21 |
| 4 | Confid | Cover Letter(s) Adobe Acrobat PDF (74 kB) |
2012-11-21 2012-11-21 |
| 4 | Instructions | Users Manual Adobe Acrobat PDF (100 kB) |
2012-11-21 2012-11-21 |
| 4 | Test Setup | Test Setup Photos Adobe Acrobat PDF (933 kB) |
2012-11-21 2012-11-21 |
| 4 | 15E Report | Test Report Adobe Acrobat PDF (828 kB) |
2012-11-21 2012-11-21 |
| 3 | Manual | Users Manual Adobe Acrobat PDF (980 kB) |
2012-11-21 2012-11-21 |
| 3 | RF Exposure Info RFx | RF Exposure Info Adobe Acrobat PDF (52 kB) |
2012-11-21 2012-11-21 |
| 3 | Label and Location | ID Label/Location Info Adobe Acrobat PDF (210 kB) |
2012-11-21 2012-11-21 |
| 3 | L 452 | Internal Photos Adobe Acrobat PDF (1480 kB) |
2012-11-21 2012-11-21 |
| 3 | L 451 | Internal Photos Adobe Acrobat PDF (1817 kB) |
2012-11-21 2012-11-21 |
| 3 | L 452 | External Photos Adobe Acrobat PDF (1194 kB) |
2012-11-21 2012-11-21 |
| 3 | L 451 | External Photos Adobe Acrobat PDF (1217 kB) |
2012-11-21 2012-11-21 |
| 3 | DofC | Cover Letter(s) Adobe Acrobat PDF (71 kB) |
2012-11-21 2012-11-21 |
| 3 | L 452 Info | RF Exposure Info Adobe Acrobat PDF (46 kB) |
2012-11-21 2012-11-21 |
| 3 | Channel Declaration | Cover Letter(s) Adobe Acrobat PDF (54 kB) |
2012-11-21 2012-11-21 |
| 3 | Authorization | Cover Letter(s) Adobe Acrobat PDF (11 kB) |
2012-11-21 2012-11-21 |
| 3 | Confid | Cover Letter(s) Adobe Acrobat PDF (74 kB) |
2012-11-21 2012-11-21 |
| 3 | Instructions | Users Manual Adobe Acrobat PDF (100 kB) |
2012-11-21 2012-11-21 |
| 3 | Test Setup | Test Setup Photos Adobe Acrobat PDF (933 kB) |
2012-11-21 2012-11-21 |
| 3 | 15C Report | Test Report Adobe Acrobat PDF (1388 kB) |
2012-11-21 2012-11-21 |
| 1 | Attestation Statement Ad Hoc Declaration | Attestation Statements Adobe Acrobat PDF (21 kB) |
2010-12-01 2010-12-01 |
| 1 | Cover Letter Modular Approval Request | Cover Letter(s) Adobe Acrobat PDF (30 kB) |
2010-12-01 2010-12-01 |
| 1 | Cover Letter Agent Authorization | Cover Letter(s) Adobe Acrobat PDF (30 kB) |
2010-12-01 2010-12-01 |
| 1 | Confidentiality Request | Cover Letter(s) Adobe Acrobat PDF (29 kB) |
2010-12-01 2010-12-01 |
| 1 | RF Exposure Info | RF Exposure Info Adobe Acrobat PDF (37 kB) |
2010-12-01 2010-12-01 |
| 1 | User Manual | Users Manual Adobe Acrobat PDF (1815 kB) |
2010-12-01 2010-12-01 |
| 1 | Test Setup Photos | Test Setup Photos Adobe Acrobat PDF (317 kB) |
2010-12-01 2010-12-01 |
| 1 | Test Report - 15E | Test Report Adobe Acrobat PDF (624 kB) |
2010-12-01 2010-12-01 |
| 1 | Test Report - 15C | Test Report Adobe Acrobat PDF (1024 kB) |
2010-12-01 2010-12-01 |
| 1 | Operational Description | Operational Description Adobe Acrobat PDF (31 kB) |
2010-12-01 2010-12-01 |
| 1 | Internal Photos | Internal Photos Adobe Acrobat PDF (100 kB) |
2010-12-01 2010-12-01 |
| 1 | Label Location | ID Label/Location Info Adobe Acrobat PDF (52 kB) |
2010-12-01 2010-12-01 |
| 1 | Label | ID Label/Location Info Adobe Acrobat PDF (28 kB) |
2010-12-01 2010-12-01 |
| 1 | External Photos | External Photos Adobe Acrobat PDF (294 kB) |
2010-12-01 2010-12-01 |
| 2 | Cover Letter Modular Approval Request | Cover Letter(s) Adobe Acrobat PDF (30 kB) |
2010-12-01 2010-12-01 |
| 2 | Cover Letter Agent Authorization | Cover Letter(s) Adobe Acrobat PDF (30 kB) |
2010-12-01 2010-12-01 |
| 2 | RF Exposure Info | RF Exposure Info Adobe Acrobat PDF (37 kB) |
2010-12-01 2010-12-01 |
| 2 | Attestation Statement Ad Hoc Declaration | Attestation Statements Adobe Acrobat PDF (21 kB) |
2010-12-01 2010-12-01 |
| 2 | Confidentiality Request | Cover Letter(s) Adobe Acrobat PDF (29 kB) |
2010-12-01 2010-12-01 |
| 2 | User Manual | Users Manual Adobe Acrobat PDF (1815 kB) |
2010-12-01 2010-12-01 |
| 2 | Test Setup Photos | Test Setup Photos Adobe Acrobat PDF (317 kB) |
2010-12-01 2010-12-01 |
| 2 | Test Report - 15E | Test Report Adobe Acrobat PDF (624 kB) |
2010-12-01 2010-12-01 |
| 2 | Test Report - 15C | Test Report Adobe Acrobat PDF (1024 kB) |
2010-12-01 2010-12-01 |
| 2 | Operational Description | Operational Description Adobe Acrobat PDF (31 kB) |
2010-12-01 2010-12-01 |
| 2 | Internal Photos | Internal Photos Adobe Acrobat PDF (100 kB) |
2010-12-01 2010-12-01 |
| 2 | Label Location | ID Label/Location Info Adobe Acrobat PDF (52 kB) |
2010-12-01 2010-12-01 |
| 2 | Label | ID Label/Location Info Adobe Acrobat PDF (28 kB) |
2010-12-01 2010-12-01 |
| 2 | External Photos | External Photos Adobe Acrobat PDF (294 kB) |
2010-12-01 2010-12-01 |
APP # 5 (2016-05-25)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 5 | Users Manual.pdf | Users Manual Adobe Acrobat PDF (1119 kB) |
2016-05-25 00:00:00 2016-05-25 00:00:00 |
| 5 | Cover Letter (no power levels increased for U-NII-3).pdf | Cover Letter(s) Adobe Acrobat PDF (42 kB) |
2016-05-25 00:00:00 2016-05-25 00:00:00 |
| 5 | Cover Letter (no power levels increased for U-NII-1).pdf | Cover Letter(s) Adobe Acrobat PDF (41 kB) |
2016-05-25 00:00:00 2016-05-25 00:00:00 |
| 5 | Cover Letter (Hardware Antenna Attestation).pdf | Cover Letter(s) Adobe Acrobat PDF (41 kB) |
2016-05-25 00:00:00 2016-05-25 00:00:00 |
| 5 | Cover Letter (Description of Change).pdf | Cover Letter(s) Adobe Acrobat PDF (11 kB) |
2016-05-25 00:00:00 2016-05-25 00:00:00 |
| 5 | Cover Letter (Agent Authorization).pdf | Cover Letter(s) Adobe Acrobat PDF (49 kB) |
2016-05-25 00:00:00 2016-05-25 00:00:00 |
| 5 | Confidentiality Request.pdf | Cover Letter(s) Adobe Acrobat PDF (50 kB) |
2016-05-25 00:00:00 2016-05-25 00:00:00 |
APP # 4 (2012-11-21)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 4 | Manual | Users Manual Adobe Acrobat PDF (980 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 4 | RF Exposure Info RFx | RF Exposure Info Adobe Acrobat PDF (52 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 4 | Label and Location | ID Label/Location Info Adobe Acrobat PDF (210 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 4 | L 452 | Internal Photos Adobe Acrobat PDF (1480 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 4 | L 451 | Internal Photos Adobe Acrobat PDF (1817 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 4 | L 452 | External Photos Adobe Acrobat PDF (1194 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 4 | L 451 | External Photos Adobe Acrobat PDF (1217 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 4 | DofC | Cover Letter(s) Adobe Acrobat PDF (71 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 4 | L 452 Declaration | RF Exposure Info Adobe Acrobat PDF (46 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 4 | Authorization | Cover Letter(s) Adobe Acrobat PDF (11 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 4 | Confid | Cover Letter(s) Adobe Acrobat PDF (74 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 4 | Instructions | Users Manual Adobe Acrobat PDF (100 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 4 | Test Setup | Test Setup Photos Adobe Acrobat PDF (933 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 4 | 15E Report | Test Report Adobe Acrobat PDF (828 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
APP # 3 (2012-11-21)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 3 | Manual | Users Manual Adobe Acrobat PDF (980 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | RF Exposure Info RFx | RF Exposure Info Adobe Acrobat PDF (52 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | Label and Location | ID Label/Location Info Adobe Acrobat PDF (210 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | L 452 | Internal Photos Adobe Acrobat PDF (1480 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | L 451 | Internal Photos Adobe Acrobat PDF (1817 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | L 452 | External Photos Adobe Acrobat PDF (1194 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | L 451 | External Photos Adobe Acrobat PDF (1217 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | DofC | Cover Letter(s) Adobe Acrobat PDF (71 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | L 452 Info | RF Exposure Info Adobe Acrobat PDF (46 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | Channel Declaration | Cover Letter(s) Adobe Acrobat PDF (54 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | Authorization | Cover Letter(s) Adobe Acrobat PDF (11 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | Confid | Cover Letter(s) Adobe Acrobat PDF (74 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | Instructions | Users Manual Adobe Acrobat PDF (100 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | Test Setup | Test Setup Photos Adobe Acrobat PDF (933 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
| 3 | 15C Report | Test Report Adobe Acrobat PDF (1388 kB) |
2012-11-21 00:00:00 2012-11-21 00:00:00 |
APP # 1 (2010-12-01)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 1 | Attestation Statement Ad Hoc Declaration | Attestation Statements Adobe Acrobat PDF (21 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 1 | Cover Letter Modular Approval Request | Cover Letter(s) Adobe Acrobat PDF (30 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 1 | Cover Letter Agent Authorization | Cover Letter(s) Adobe Acrobat PDF (30 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 1 | Confidentiality Request | Cover Letter(s) Adobe Acrobat PDF (29 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 1 | RF Exposure Info | RF Exposure Info Adobe Acrobat PDF (37 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 1 | User Manual | Users Manual Adobe Acrobat PDF (1815 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 1 | Test Setup Photos | Test Setup Photos Adobe Acrobat PDF (317 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 1 | Test Report - 15E | Test Report Adobe Acrobat PDF (624 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 1 | Test Report - 15C | Test Report Adobe Acrobat PDF (1024 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 1 | Operational Description | Operational Description Adobe Acrobat PDF (31 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 1 | Internal Photos | Internal Photos Adobe Acrobat PDF (100 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 1 | Label Location | ID Label/Location Info Adobe Acrobat PDF (52 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 1 | Label | ID Label/Location Info Adobe Acrobat PDF (28 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 1 | External Photos | External Photos Adobe Acrobat PDF (294 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
APP # 2 (2010-12-01)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 2 | Cover Letter Modular Approval Request | Cover Letter(s) Adobe Acrobat PDF (30 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 2 | Cover Letter Agent Authorization | Cover Letter(s) Adobe Acrobat PDF (30 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 2 | RF Exposure Info | RF Exposure Info Adobe Acrobat PDF (37 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 2 | Attestation Statement Ad Hoc Declaration | Attestation Statements Adobe Acrobat PDF (21 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 2 | Confidentiality Request | Cover Letter(s) Adobe Acrobat PDF (29 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 2 | User Manual | Users Manual Adobe Acrobat PDF (1815 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 2 | Test Setup Photos | Test Setup Photos Adobe Acrobat PDF (317 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 2 | Test Report - 15E | Test Report Adobe Acrobat PDF (624 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 2 | Test Report - 15C | Test Report Adobe Acrobat PDF (1024 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 2 | Operational Description | Operational Description Adobe Acrobat PDF (31 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 2 | Internal Photos | Internal Photos Adobe Acrobat PDF (100 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 2 | Label Location | ID Label/Location Info Adobe Acrobat PDF (52 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 2 | Label | ID Label/Location Info Adobe Acrobat PDF (28 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
| 2 | External Photos | External Photos Adobe Acrobat PDF (294 kB) |
2010-12-01 00:00:00 2010-12-01 00:00:00 |
APP # 3 (2012-11-21)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 3 | External Photos Ops | Operational Description Adobe Acrobat PDF (133 kB) |
2012-11-21 00:00:00 N/A |
APP # 4 (2012-11-21)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 4 | External Photos Ops | Operational Description Adobe Acrobat PDF (133 kB) |
2012-11-21 00:00:00 N/A |
APP # 3 (2012-11-21)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 3 | Schema | Schematics Adobe Acrobat PDF (354 kB) |
2012-11-21 00:00:00 N/A |
APP # 4 (2012-11-21)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 4 | Schema | Schematics Adobe Acrobat PDF (354 kB) |
2012-11-21 00:00:00 N/A |
APP # 2 (2010-12-01)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 2 | Block Diagram | Block Diagram Adobe Acrobat PDF (402 kB) |
2010-12-01 00:00:00 N/A |
APP # 3 (2012-11-21)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 3 | Block | Block Diagram Adobe Acrobat PDF (106 kB) |
2012-11-21 00:00:00 N/A |
APP # 4 (2012-11-21)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 4 | Block | Block Diagram Adobe Acrobat PDF (106 kB) |
2012-11-21 00:00:00 N/A |
APP # 3 (2012-11-21)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 3 | Mini Nanoblade | Schematics Adobe Acrobat PDF (1430 kB) |
2012-11-21 00:00:00 N/A |
APP # 4 (2012-11-21)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 4 | Mini Nanoblade | Schematics Adobe Acrobat PDF (1430 kB) |
2012-11-21 00:00:00 N/A |
APP # 1 (2010-12-01)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 1 | Schematics | Schematics Adobe Acrobat PDF (202 kB) |
2010-12-01 00:00:00 N/A |
APP # 3 (2012-11-21)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 3 | Swivel | Schematics Adobe Acrobat PDF (343 kB) |
2012-11-21 00:00:00 N/A |
APP # 4 (2012-11-21)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 4 | Swivel | Schematics Adobe Acrobat PDF (343 kB) |
2012-11-21 00:00:00 N/A |
APP # 3 (2012-11-21)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 3 | Cable Spec | Schematics Adobe Acrobat PDF (445 kB) |
2012-11-21 00:00:00 N/A |
APP # 1 (2010-12-01)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 1 | Block Diagram | Block Diagram Adobe Acrobat PDF (402 kB) |
2010-12-01 00:00:00 N/A |
APP # 2 (2010-12-01)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 2 | Schematics | Schematics Adobe Acrobat PDF (202 kB) |
2010-12-01 00:00:00 N/A |
APP # 5 (2016-05-25)
| App # | Document | Type | Submitted Available |
|---|---|---|---|
| 5 | Software Operating Description.pdf | Operational Description Adobe Acrobat PDF (184 kB) |
2016-05-25 00:00:00 N/A |
Application Forms
| Application for Equipment Authorization FCC Form 731 TCB Version |
WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT
(U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR
CONSTRUCTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE
(U.S. CODE, TITLE 47, SECTION 503).
| Application for Equipment Authorization FCC Form 731 TCB Version |
WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT
(U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR
CONSTRUCTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE
(U.S. CODE, TITLE 47, SECTION 503).
| Application for Equipment Authorization FCC Form 731 TCB Version |
WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT
(U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR
CONSTRUCTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE
(U.S. CODE, TITLE 47, SECTION 503).
| Application for Equipment Authorization FCC Form 731 TCB Version |
WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT
(U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR
CONSTRUCTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE
(U.S. CODE, TITLE 47, SECTION 503).
| Application for Equipment Authorization FCC Form 731 TCB Version |
WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT
(U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR
CONSTRUCTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE
(U.S. CODE, TITLE 47, SECTION 503).
Applications are submitted for FCC ID and Grant requests. Click an above application to view details
Grants
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: | ||
|
Curtis-Straus LLC One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 12/01/2010 |
| Wistron NeWeb Corporation |
| 20 Park Avenue II |
| Hsinchu Science Park |
| Hsinchu, 308 Taiwan |
| Attention: Edward Yeh , Senior Engineer / System Engineering dept. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | NKR-DNXAH1 |
| Name of Grantee: | Wistron NeWeb Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | PCIe 802.11n WiFi module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.036 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure conditions, Device is an 802.11abgn WiFi module operating in a 3x3 or 2x2 MIMO configuration as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification | ||
|
Wistron NeWeb Corporation 20 Park Avenue II Hsinchu Science Park Hsinchu, 308 Taiwan |
Date of Grant: 12/01/2010 |
| Attention: Edward Yeh , Senior Engineer / System Engineering dept. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | NKR-DNXAH1 |
| Name of Grantee: | Wistron NeWeb Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | PCIe 802.11n WiFi module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.036 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure conditions, Device is an 802.11abgn WiFi module operating in a 3x3 or 2x2 MIMO configuration as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
EA475685 |
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: | ||
|
Curtis-Straus LLC One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 05/25/2016 |
| Wistron NeWeb Corporation |
| 20 Park Avenue II |
| Hsinchu Science Park |
| Hsinchu, 308 Taiwan |
| Attention: Edward Yeh , Senior Engineer / System Engineering dept. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | NKR-DNXAH1 |
| Name of Grantee: | Wistron NeWeb Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | PCIe 802.11n WiFi module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.036 | ||
| 49 CC MO | 15E | 5745.0 - 5825.0 | 0.287 |
| Class II Permissive Change to update 5.2GHz and 5.8GHz band. This change is for a device previously granted under rule parts of 15.247 of U-NII-3 band and is now applying for approval under 15.407(b)(4)(ii) for devices with antenna gains less than 10dBi and update U-NII-1 band to new rule with no changes to hardware or output power. Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure conditions, Device is an 802.11abgn WiFi module operating in a 3x3 or 2x2 MIMO configuration as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| 49: | The device has been approved under § 15.407(b)(4)(ii) for antenna gains of 10 dBi or less and cannot be manufactured, marketed, sold or imported after March 2, 2020. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification | ||
|
Wistron NeWeb Corporation 20 Park Avenue II Hsinchu Science Park Hsinchu, 308 Taiwan |
Date of Grant: 05/25/2016 |
| Attention: Edward Yeh , Senior Engineer / System Engineering dept. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | NKR-DNXAH1 |
| Name of Grantee: | Wistron NeWeb Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | PCIe 802.11n WiFi module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.036 | ||
| 49 CC MO | 15E | 5745.0 - 5825.0 | 0.287 |
| Class II Permissive Change to update 5.2GHz and 5.8GHz band. This change is for a device previously granted under rule parts of 15.247 of U-NII-3 band and is now applying for approval under 15.407(b)(4)(ii) for devices with antenna gains less than 10dBi and update U-NII-1 band to new rule with no changes to hardware or output power. Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure conditions, Device is an 802.11abgn WiFi module operating in a 3x3 or 2x2 MIMO configuration as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| 49: | The device has been approved under § 15.407(b)(4)(ii) for antenna gains of 10 dBi or less and cannot be manufactured, marketed, sold or imported after March 2, 2020. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
EA404776 |
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: | ||
|
MiCOM Labs 575 Boulder Court Pleasanton, CA 94566 |
Date of Grant: 11/21/2012 |
| Wistron NeWeb Corporation |
| 20 Park Avenue II |
| Hsinchu Science Park |
| Hsinchu, 308 Taiwan |
| Attention: Edward Yeh , Senior Engineer / System Engineering dept. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | NKR-DNXAH1 |
| Name of Grantee: | Wistron NeWeb Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | PCIe 802.11n WiFi module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.732 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.287 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure conditions, Device is an 802.11abgn WiFi module operating in a 3x3 or 2x2 MIMO configuration as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. This filing adds LANCOMS system hosts model L-451 and L-452, exact RF cable specifications, and two additional antennas. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification | ||
|
Wistron NeWeb Corporation 20 Park Avenue II Hsinchu Science Park Hsinchu, 308 Taiwan |
Date of Grant: 11/21/2012 |
| Attention: Edward Yeh , Senior Engineer / System Engineering dept. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | NKR-DNXAH1 |
| Name of Grantee: | Wistron NeWeb Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | PCIe 802.11n WiFi module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.732 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.287 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure conditions, Device is an 802.11abgn WiFi module operating in a 3x3 or 2x2 MIMO configuration as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. This filing adds LANCOMS system hosts model L-451 and L-452, exact RF cable specifications, and two additional antennas. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
EA613487 |
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: | ||
|
MiCOM Labs 575 Boulder Court Pleasanton, CA 94566 |
Date of Grant: 11/21/2012 |
| Wistron NeWeb Corporation |
| 20 Park Avenue II |
| Hsinchu Science Park |
| Hsinchu, 308 Taiwan |
| Attention: Edward Yeh , Senior Engineer / System Engineering dept. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | NKR-DNXAH1 |
| Name of Grantee: | Wistron NeWeb Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | PCIe 802.11n WiFi module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.036 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure conditions, Device is an 802.11abgn WiFi module operating in a 3x3 or 2x2 MIMO configuration as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. This filing adds LANCOMS system hosts model L-451 and L-452, exact RF cable specifications, and two additional antennas. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification | ||
|
Wistron NeWeb Corporation 20 Park Avenue II Hsinchu Science Park Hsinchu, 308 Taiwan |
Date of Grant: 11/21/2012 |
| Attention: Edward Yeh , Senior Engineer / System Engineering dept. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | NKR-DNXAH1 |
| Name of Grantee: | Wistron NeWeb Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | PCIe 802.11n WiFi module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.036 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure conditions, Device is an 802.11abgn WiFi module operating in a 3x3 or 2x2 MIMO configuration as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. This filing adds LANCOMS system hosts model L-451 and L-452, exact RF cable specifications, and two additional antennas. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
EA898711 |
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: | ||
|
Curtis-Straus LLC One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 12/01/2010 |
| Wistron NeWeb Corporation |
| 20 Park Avenue II |
| Hsinchu Science Park |
| Hsinchu, 308 Taiwan |
| Attention: Edward Yeh , Senior Engineer / System Engineering dept. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | NKR-DNXAH1 |
| Name of Grantee: | Wistron NeWeb Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | PCIe 802.11n WiFi module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.732 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.287 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure conditions, Device is an 802.11abgn WiFi module operating in a 3x3 or 2x2 MIMO configuration as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification | ||
|
Wistron NeWeb Corporation 20 Park Avenue II Hsinchu Science Park Hsinchu, 308 Taiwan |
Date of Grant: 12/01/2010 |
| Attention: Edward Yeh , Senior Engineer / System Engineering dept. |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | NKR-DNXAH1 |
| Name of Grantee: | Wistron NeWeb Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | PCIe 802.11n WiFi module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.732 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.287 |
| Power listed is the maximum combined conducted output power. Single Modular Approval for mobile RF Exposure conditions, Device is an 802.11abgn WiFi module operating in a 3x3 or 2x2 MIMO configuration as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Approval is limited to OEM installation only. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
EA660613 |
