DHUME997 Marvell 88W8997 11ac 2x2 and BT... - FCC ID NKR-DHUME997
FCC ID NKR-DHUME997
Photos-Test Setup_R1.pdf
Marvell 88W8997 11ac 2x2 and BT Combo module
Document preview loads when visible.
Document Details
| FCC ID | NKR-DHUME997 |
|---|---|
| Document ID | 3943398 |
| Document Type | Test Setup Photos |
| Description | Photos-Test Setup_R1.pdf |
| Document Title | RF180223C02__TSup Photo_ |
| Applicant | Wistron NeWeb Corporation |
| Equipment Class | Marvell 88W8997 11ac 2x2 and BT Combo module |
| Product Code | DHUME997 |
| Application ID | dsUIvvzl5j1t8dcIlwE7gg== |
| Application Purpose | Original Equipment |
| Application Date | 2018-07-30 |
| Frequency Range | 5180-5240 MHz |
| FRN | 0006053789 |
| Test Firm | Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch |
| Certified By | Annie Cheng Supervisor |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 01/26/2019 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2018-07-30 |
| Available | 2019-01-26 |
| Created | 2018-07-16 |
| Modified | 2018-07-16 |
| Pages | 6 |
| File Type | Adobe Acrobat PDF |
| File Size | 572641 |
| File SHA-256 | 1bfa3ea466d3c24a6a1e889e409d11a5508e9100ae5b19ef05dccfb7464646c7 |
| PDF Metadata Author | pochien |
| PDF Metadata Producer | pochien Acrobat Distiller 11.0 (Windows) |
| FCC.gov Sources | FCC.gov 3943398, FCC.gov 3943328, FCC.gov 3943305 |
