XRBH1 BLE Module Test Setup Photos - FCC ID NKR-XRBH-1

FCC ID NKR-XRBH-1

Test setup

BLE Module

by Wistron NeWeb Corporation

Document preview loads when visible.

Document Details

FCC IDNKR-XRBH-1
Document ID3389569
Document TypeTest Setup Photos
DescriptionTest setup
Document Title17LR085FCDTS (Part15 247) BT4.2
ApplicantWistron NeWeb Corporation
Equipment ClassBLE Module
Product CodeXRBH1
Application IDUcXQtQsBqGpAms2dGUpbmw==
Application PurposeOriginal Equipment
Application Date2017-05-14
Frequency Range2402-2480 MHz
FRN0006053789
Test FirmInternational Standards Laboratory Corp.
Certified BySam Kao Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2017-05-14
Available2017-05-14
Created2017-10-24
Modified2017-10-24
Pages5
File TypeAdobe Acrobat PDF
File Size319431
File SHA-256956c09f1cdaef017b2f0d0bf4a8d01eaf1eb3befc45f1e228afae8b9ef2f5cec
PDF Metadata Author10003808
PDF Metadata ProducerGPL Ghostscript 9.18 10003808
FCC.gov SourcesFCC.gov 3389569
