FCC ID NLMSWLQ93T
WiFi Module
by Hanwha Techwin Co., Ltd.
Grantee Code: NLM Product Code: SWLQ93T
Latest application date: 2015-12-23
Device Images
FCC ID Device Details
| FCC ID | NLMSWLQ93T |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | NLM |
| Product Code | SWLQ93T |
| Applicant Business | Hanwha Techwin Co., Ltd. 🇰🇷 |
| Related Domains |  hanwha.com |
| Equipment Class | WiFi Module |
| Test Firm | KES Co., Ltd |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2015-12-23 |
| 2412-2462 MHz | Original Equipment | 2015-12-23 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2015-12-23 | PDF 310.2 KB |
| Internal Photos | Internal Photos | 2015-12-23 | PDF 394.3 KB |
| External Photos | External Photos | 2015-12-23 | PDF 451.5 KB |
| Label | ID Label/Location Info | 2015-12-23 | PDF 304.8 KB |
| Test Setup Photos | Test Setup Photos | 2015-12-23 | PDF 228.6 KB |
| Test Report | Test Report | 2015-12-23 | PDF 3.5 MB |
| Test Report DFS | Test Report | 2015-12-23 | PDF 2.1 MB |
| Test Report Part 1 | Test Report | 2015-12-23 | PDF 3.9 MB |
| Test Report Part 2 | Test Report | 2015-12-23 | PDF 3 MB |
| Agent Authorization Letter | Cover Letter(s) | 2015-12-23 | PDF 85.9 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2015-12-23 | PDF 100.3 KB |
| Modular Approval Letter | Cover Letter(s) | 2015-12-23 | PDF 244.3 KB |
| RF Exposure | RF Exposure Info | 2015-12-23 | PDF 103 KB |
| Block Diagram Metadata only | Block Diagram | PDF 63.8 KB | |
| PCB Layout Metadata only | Schematics | PDF 168.5 KB | |
| Schematics Metadata only | Schematics | PDF 175.1 KB | |
| Operational Description Antenna Spec Metadata only | Operational Description | PDF 3.9 MB | |
| Operational Description Antenna Specification Metadata only | Operational Description | PDF 3.9 MB | |
| Operational Description Software Secuirty Metadata only | Operational Description | PDF 139.7 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 84.4 KB |
Application Information
| Application ID | MrrbIfiq93xb44pjK43Zww== |
|---|---|
| Final Action Date | 2015-12-23 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0020229910 |
| Model | SWLQ93T |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | WiFi Module |
| Responsible Party | JEISOON KANG, Principal Research Engineer, js2002.kang@hanwha.com , 82-70-7147-8376 |
| Test Firm | Insung Ryu, KES Co., Ltd, kes@kes.co.kr  , 82-31-425-6200 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Power listed is maximum combined conducted output power. This device is restricted to fixed and mobile use only. Device operates with specific antennas in MIMO configurations as described in this filing. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except as evaluated in this filing or in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20 MHz and 40 MHz bandwidth modes. |
