0PL4200 Smartphone Test Setup Photos - FCC ID NM80PL4200

FCC ID NM80PL4200

Test Setup Photos RF Exposure

Smartphone

by HTC Corporation

Document preview loads when visible.

Document Details

FCC IDNM80PL4200
Document ID2523454
Document TypeTest Setup Photos
DescriptionTest Setup Photos RF Exposure
Document TitleFA4D0804_R01_FCC SAR_HTC_0PL4200_Appendix D
ApplicantHTC Corporation
Equipment ClassSmartphone
Product Code0PL4200
Application IDtiEY0No0uydsnuij3OMs2Q==
Application PurposeOriginal Equipment
Application Date2015-02-09
Frequency Range1850.2-1909.8 MHz
FRN0018127647
Test FirmSPORTON INTERNATIONAL(KUN SHAN)INC.
Certified ByJones Tsai Director
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date08/03/2015
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2015-02-04
Available2015-08-03
Created2015-02-02
Modified2015-02-02
Pages2
File TypeAdobe Acrobat PDF
File Size521762
File SHA-2562045d4acedd2c4a527d026345fba66655af00fd4e882ae5a8318c3dc8aa71aff
PDF Metadata AuthorVeraCheng
PDF Metadata ProducerVeraCheng Acrobat Distiller 9.0.0 (Windows)
FCC.gov SourcesFCC.gov 2523454
