DAS9M4EW LGCell EGSM Label Diagram - FCC ID NOODAS9M-4E-W

FCC ID NOODAS9M-4E-W

Label

LGCell EGSM

by ADC Telecommunications Inc.

Document preview loads when visible.

Document Details

FCC IDNOODAS9M-4E-W
Document ID166292
Document TypeID Label/Location Info
DescriptionLabel
ApplicantADC Telecommunications Inc.
Equipment ClassLGCell EGSM
Product CodeDAS9M4EW
Application IDE6mq0QSCuW4pz2ZrIQMAzg==
Application PurposeOriginal Equipment
Application Date2001-08-24
Frequency Range880-915 MHz
FRN0008274896
Test FirmMET Laboratories
Certified ByHarry Ward EMC & Radio Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2001-08-24
Available2001-08-24
Created2001-07-19
Modified2001-07-19
Pages1
File TypeAdobe Acrobat PDF
File Size33275
File SHA-25645554befcb393737142dfe8ff3705fcfb39e0517bb1a170a20eb0ff38d55efc9
PDF Metadata ProducerAcrobat Distiller 4.0 for Windows
FCC.gov SourcesFCC.gov 166292
