M70BP070B071B Wireless Microphone... - FCC ID NPXM70B-P070B071B

FCC ID NPXM70B-P070B071B

schematics

Wireless Microphone System

by Prince Electronics Co

Document preview loads when visible.

Document Details

FCC IDNPXM70B-P070B071B
Document ID641958
Document TypeSchematics
Descriptionschematics
Document TitleNone
ApplicantPrince Electronics Co
Equipment ClassWireless Microphone System
Product CodeM70BP070B071B
Application IDzLpoo+UPjYesoj/p0bxuEw==
Application PurposeOriginal Equipment
Application Date2006-03-28
Frequency Range741.2-751.8 MHz
FRN0005929278
Test FirmBay Area Compliance Laboratory
Certified BySu Chul Song
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2006-03-29
Available2006-03-28
Created2005-12-06
Modified2005-12-06
Pages6
File TypeAdobe Acrobat PDF
File Size112165
File SHA-256e446b40cdcae2baeb4cf38cfbfd699b4e918f7375129283b69b31f9ef3d7bddb
PDF Metadata AuthorNone
PDF Metadata CreatorNone
PDF Metadata ProducerAcrobat Distiller 5.0 (Windows)
FCC.gov SourcesFCC.gov 641958
