FCC ID NS9VIP4GABGN20
LTE Ethernet Bridge / Serial Gateway
by Microhard Systems Inc
Grantee Code: NS9 Product Code: VIP4GABGN20
Latest application date: 2016-08-16
Device Images
FCC ID Device Details
| FCC ID | NS9VIP4GABGN20 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | NS9 |
| Product Code | VIP4GABGN20 |
| Applicant Business | Microhard Systems Inc 🇨🇦 |
| Related Domains |  microhardcorp.com |
| Equipment Class | LTE Ethernet Bridge / Serial Gateway |
| Test Firm | UltraTech Engineering Labs Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5745-5825 MHz | Original Equipment | 2016-08-16 |
| 2412-2462 MHz | Original Equipment | 2013-05-21 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual 1 of 2 | Users Manual | 2016-08-16 | PDF 3.6 MB |
| User Manual 2 of 2 | Users Manual | 2016-08-16 | PDF 3.1 MB |
| User manual | Users Manual | 2013-11-17 | PDF 662.4 KB |
| Internal Photos | Internal Photos | 2016-08-16 | PDF 1.1 MB |
| Internal photos | Internal Photos | 2013-11-17 | PDF 2.7 MB |
| External Photos | External Photos | 2016-08-16 | PDF 546.5 KB |
| External photos | External Photos | 2013-11-17 | PDF 1.6 MB |
| ID Label and Location | ID Label/Location Info | 2016-08-16 | PDF 137.4 KB |
| Label | ID Label/Location Info | 2013-05-21 | PDF 55 KB |
| Test Setup Photos | Test Setup Photos | 2016-08-16 | PDF 370 KB |
| Test setup photos | Test Setup Photos | 2013-11-17 | PDF 370 KB |
| Test setup photos | Test Setup Photos | 2013-11-17 | PDF 450.9 KB |
| DTS Test Report | Test Report | 2016-08-16 | PDF 1.9 MB |
| NII Test Report | Test Report | 2016-08-16 | PDF 712.4 KB |
| Test report | Test Report | 2013-05-21 | PDF 1.9 MB |
| Test report | Test Report | 2013-05-21 | PDF 558.9 KB |
| 15.407(c) | Attestation Statements | 2016-08-16 | PDF 85.8 KB |
| Hardware and Antenna | Attestation Statements | 2016-08-16 | PDF 106.9 KB |
| Manufacturer | Attestation Statements | 2016-08-16 | PDF 96.3 KB |
| Attestation letter | Cover Letter(s) | 2013-05-21 | PDF 19.5 KB |
| Agent Authorization | Cover Letter(s) | 2016-08-16 | PDF 96.1 KB |
| Confidentiality Request | Cover Letter(s) | 2016-08-16 | PDF 164.2 KB |
| Cover Letter | Cover Letter(s) | 2016-08-16 | PDF 63.1 KB |
| Software Security | Cover Letter(s) | 2016-08-16 | PDF 531 KB |
| Third-party Confidentiality Request | Cover Letter(s) | 2016-08-16 | PDF 307.7 KB |
| Agents letter | Cover Letter(s) | 2013-05-21 | PDF 20.4 KB |
| Confidentiality letter - permanent | Cover Letter(s) | 2013-05-21 | PDF 20.7 KB |
| Confidentiality letter - short term | Cover Letter(s) | 2013-05-21 | PDF 19 KB |
| MPE | RF Exposure Info | 2016-08-16 | PDF 445.2 KB |
| RI7LN930 MPE | RF Exposure Info | 2016-08-16 | PDF 756.4 KB |
| RF exposure info. | RF Exposure Info | 2013-05-21 | PDF 114.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 7 KB | |
| Schematics Metadata only | Schematics | PDF 59.5 KB | |
| Operational Description Metadata only | Operational Description | PDF 14.8 KB |
Application Information
| Application ID | zvsGuKL2DgJQv5RbSkiB4A== |
|---|---|
| Final Action Date | 2016-08-16 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0007211139 |
| Model | VIP4GABGN20 |
| Frequency Range | 5745-5825 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | LTE Ethernet Bridge / Serial Gateway |
| Responsible Party | Hany Shenouda, President, Shenouda@microhardcorp.com , 403 248-0028 |
| Agent | Dan Dan Dan, UltraTech Engineering Labs Inc, dan@ultratech-labs.com  , 905-829-1570 |
| Test Firm | Tri Luu, UltraTech Engineering Labs Inc., tri@ultratech-labs.com , 905-829-1570 |
| TCB Email | vic@ultratech-labs.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is conducted. This device has 20 MHz and 40 MHz bandwidth modes. Transmitter antenna types, gains and installation shall meet the requirements instructed in the user’s manual of this filing and shall not be collocated or operating in conjunction with any other antennas, except in accordance with FCC multi-transmitter product procedures. For operations in mobile RF exposure conditions, the antenna used for this transmitter shall be installed to provide a separation distance of at least 20 cm from all persons. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| zvsGuKL2DgJQv5RbSkiB4A== | 2016-08-16 | Original Equipment |
| xx8FLqMaznvnrUNZDT9j0g== | 2013-05-21 | Original Equipment |
| wwaF1Z5FlHkvWt3Su47Acg== | 2013-05-21 | Original Equipment |
Equipment Authorization
| Frequency | Output | Emission | Rules | Grant Notes |
|---|---|---|---|---|
| 15B | CC | |||
| 2412-2462 MHz | 0.077 | 15M8D2W | 15C | CC |
| 2412-2462 MHz | 0.335 | 16M5D7W | 15C | CC |
| 2412-2462 MHz | 0.398 | 17M7D7W | 15C | CC |
| 2422-2452 MHz | 0.247 | 36M1D7W | 15C | CC |
| 5745-5825 MHz | 0.063 | 15E | 49, CC | |
| 5745-5825 MHz | 0.034 | 15E | 49, CC, MO | |
| 5745-5825 MHz | 0.245 | 16M5D7W | 15C | CC |
| 5745-5825 MHz | 0.291 | 17M7D7W | 15C | CC |
| 5755-5795 MHz | 0.031 | 15E | 49, CC, MO | |
| 5755-5795 MHz | 0.242 | 36M1D7W | 15C | CC |
Grants
TCB Grant - Application zvsGuKL2DgJQv5RbSkiB4A==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Ultratech Engineering Labs Inc. 3000 Bristol Circle Oakville Ontario, L6H 6G4 Canada |
Date of Grant: 08/16/2016 Application Dated: 07/26/2016 |
| Microhard Systems Inc |
| 150 Country Hills Landing NW |
| Calgary, AB, T3K 5P3 Canada |
| Attention: Hany Shenouda , President |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | NS9VIP4GABGN20 |
| Name of Grantee: | Microhard Systems Inc |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | LTE Ethernet Bridge / Serial Gateway |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 49 CC | 15E | 5745.0 - 5825.0 | 0.063 | ||
| 49 CC MO | 15E | 5745.0 - 5825.0 | 0.034 | ||
| 49 CC MO | 15E | 5755.0 - 5795.0 | 0.031 |
| Power output listed is conducted. This device has 20 MHz and 40 MHz bandwidth modes. Transmitter antenna types, gains and installation shall meet the requirements instructed in the user’s manual of this filing and shall not be collocated or operating in conjunction with any other antennas, except in accordance with FCC multi-transmitter product procedures. For operations in mobile RF exposure conditions, the antenna used for this transmitter shall be installed to provide a separation distance of at least 20 cm from all persons. |
| 49: | The device has been approved under § 15.407(b)(4)(ii) for antenna gains of 10 dBi or less and cannot be manufactured, marketed, sold or imported after March 2, 2020. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
