450241CBR Z-Wave Plus Module Test Setup Photos - FCC ID NUL450241CBR

FCC ID NUL450241CBR

Test Setup Photos

Z-Wave Plus Module

by Spectrum Brands, Inc.

Document preview loads when visible.

Document Details

FCC IDNUL450241CBR
Document ID3256766
Document TypeTest Setup Photos
DescriptionTest Setup Photos
ApplicantSpectrum Brands, Inc.
Equipment ClassZ-Wave Plus Module
Product Code450241CBR
Application IDLe40LmzG1SxEs5JL6JkXHQ==
Application PurposeOriginal Equipment
Application Date2017-01-12
Frequency Range908.4-916 MHz
FRN0006821219
Test FirmCompatible Electronics, Inc.
Certified ByMatt U. Harrison Lab Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentLimited Single Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2017-01-12
Available2017-01-12
Created2016-12-27
Modified2016-12-27
Pages2
File TypeAdobe Acrobat PDF
File Size716481
File SHA-25646b6189d420751d23149b4afca907eb1cc643cf57d22723ea25ca283f02bc936
PDF Metadata ProducerAdobe Acrobat 9.0 Adobe Acrobat 9.0 Image Conversion Plug-in
FCC.gov SourcesFCC.gov 3256766
