FCC ID NVRDSP95-PAW
Industrial Signal Booster, Repeater
by Westell, Inc.
Grantee Code: NVR Product Code: DSP95PAW
Latest application date: 2016-12-24
Device Images
FCC ID Device Details
| FCC ID | NVRDSP95-PAW |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | NVR |
| Product Code | DSP95PAW |
| Applicant Business | Westell, Inc. 🇺🇸 |
| Related Domains |  westell.com |
| Equipment Class | Industrial Signal Booster, Repeater |
| Test Firm | Radiometrics Midwest Corp. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 1710-1755 MHz | Original Equipment | 2016-12-24 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-12-24 | PDF 3.8 MB |
| Int Photos | Internal Photos | 2017-02-07 | PDF 500.9 KB |
| Ext Photos | External Photos | 2016-12-24 | PDF 106.2 KB |
| FCC ID Label | ID Label/Location Info | 2016-12-24 | PDF 213.6 KB |
| Test Report | Test Report | 2016-12-24 | PDF 2.5 MB |
| Attestation Statement | Attestation Statements | 2016-12-24 | PDF 102.4 KB |
| Authorization Letter | Cover Letter(s) | 2016-12-24 | PDF 51.9 KB |
| Confidentiality Letter | Cover Letter(s) | 2016-12-24 | PDF 55.9 KB |
| RF Exposure | RF Exposure Info | 2016-12-24 | PDF 14.1 KB |
| Block Diagram Metadata only | Block Diagram | PDF 48.9 KB | |
| Schematics Metadata only | Schematics | PDF 462.6 KB | |
| Operation Description Metadata only | Operational Description | PDF 228.9 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 1.6 MB | |
| Tune up Procedure Metadata only | Parts List/Tune Up Info | PDF 51.5 KB |
Application Information
| Application ID | 92md8yRj8mboKN2Xx3WS8A== |
|---|---|
| Final Action Date | 2016-12-24 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0010374171 |
| Model | DSP95-PAW |
| Frequency Range | 1710-1755 MHz |
| Equipment Class | B2I - Part 20 Industrial Booster (CMRS) |
| Device Description | Industrial Signal Booster, Repeater |
| Responsible Party | Joseph K Gage, Compliance Engineer, jgage@westell.com , 630-375-4724 |
| Test Firm | Joseph Strzelecki, Radiometrics Midwest Corp., joe@radiomet.com  , 8152930772 |
| TCB Email | bacl.regulatory@baclcorp.com  |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 02/07/2017 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted at antenna terminals. The antennas used with this signal booster must be installed to provide a separation distance of at least 183 cm and 50 cm for uplink and downlink respectively from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. The installation height of the antenna for AWS band (1700/2100 MHz) operation is limited to 10 meters above ground for compliance with 47 CFR 27.50. Fixed, mobile, and portable (hand-held) stations operating in the 1710-1755 MHz band are limited to 1 watt EIRP. To meet EIRP limit, the gain of antenna used with this amplifier must be offset by the cable loss. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
