FCC ID NVRPS71090-PS78
Public Safety Repeater
by Westell, Inc.
Grantee Code: NVR Product Code: PS71090PS78
Latest application date: 2017-02-09
Device Images
FCC ID Device Details
| FCC ID | NVRPS71090-PS78 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | NVR |
| Product Code | PS71090PS78 |
| Applicant Business | Westell, Inc. 🇺🇸 |
| Related Domains |  westell.com |
| Equipment Class | Public Safety Repeater |
| Test Firm | Compliance Worldwide, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 758-768 MHz | Original Equipment | 2017-02-09 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-02-09 | PDF 3.4 MB |
| Internal Photos | Internal Photos | 2017-08-08 | PDF 4.4 MB |
| External Photos | External Photos | 2017-02-09 | PDF 956.4 KB |
| Label Location | ID Label/Location Info | 2017-02-09 | PDF 212.5 KB |
| Label Sample | ID Label/Location Info | 2017-02-09 | PDF 77 KB |
| Label Sample FCC Warning | ID Label/Location Info | 2017-02-09 | PDF 100 KB |
| Test Setup Photos Part 90S-20 | Test Setup Photos | 2017-02-09 | PDF 535.5 KB |
| Test Setup Photos Parts 90R-20 | Test Setup Photos | 2017-02-09 | PDF 535.1 KB |
| Test Report Part 90S-20 | Test Report | 2017-02-09 | PDF 4.5 MB |
| Test Report Parts 90R-20 | Test Report | 2017-02-09 | PDF 5.3 MB |
| Confidentiality Request | Cover Letter(s) | 2017-02-09 | PDF 57.9 KB |
| Letter of Agency | Cover Letter(s) | 2017-02-09 | PDF 58.4 KB |
| RF Exposure Part 90S-20 | RF Exposure Info | 2017-02-09 | PDF 105.3 KB |
| RF Exposure Parts 90R-20 | RF Exposure Info | 2017-02-09 | PDF 109 KB |
| Block Diagram Metadata only | Block Diagram | PDF 133.5 KB | |
| Schematics Metadata only | Schematics | PDF 4.5 MB | |
| Operational Description Metadata only | Operational Description | PDF 27.4 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 50.7 KB | |
| Tuning Procedure Metadata only | Parts List/Tune Up Info | PDF 52.2 KB |
Application Information
| Application ID | wDyDnL4WFStKfIy7DrDmCg== |
|---|---|
| Final Action Date | 2017-02-09 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0010374171 |
| Model | PS71090-PS78 |
| Frequency Range | 758-768 MHz |
| Equipment Class | B9B - Part 90 Class B Industrial Booster (non-SMR) |
| Device Description | Public Safety Repeater |
| Responsible Party | Joseph K Gage, Compliance Engineer, jgage@westell.com , 630-375-4724 |
| Test Firm | Mark McSweeney, Compliance Worldwide, Inc., mark@complianceworldwide.com  , 603-887-3903 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95, 97, & 101 (all below 3 GHz) |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 08/08/2017 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Booster. Power output is conducted. F1D and G1D emissions are included under the F1E listing, per 90.207(l). The intended use is generally for industrial/commercial use and will not be sold to the general public. Professional installation is required. The antenna(s) used for this transmitter are to be fixed-mounted on indoor or outdoor structures. RF exposure compliance will need to be addressed at the time of licensing, as required by the responsible FCC Bureau(s), including antenna co-location requirements of Sec. 1.1307(b)(3). This repeater is for private use and public safety operation. |
