GH5877H 5.8GHz/2.4GHz 40 Channel Cordless... - FCC ID NYC-GH5877H

FCC ID NYC-GH5877H

Block Diagram

5.8GHz/2.4GHz 40 Channel Cordless Phone (Handset)

by Belco International Co Ltd

Document preview loads when visible.

Document Details

FCC IDNYC-GH5877H
Document ID470161
Document TypeBlock Diagram
DescriptionBlock Diagram
Document TitleCY2401BLKH
ApplicantBelco International Co Ltd
Equipment Class5.8GHz/2.4GHz 40 Channel Cordless Phone (Handset)
Product CodeGH5877H
Application IDughao+xp/U27KEWTixr8Pw==
Application PurposeOriginal Equipment
Application Date2004-09-20
Frequency Range2468-2479.7 MHz
FRN0004265807
Test FirmIntertek Testing Services Hong Kong
Certified ByTommy Leung Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2004-09-20
Available2004-09-20
Created2004-07-09
Modified2004-09-09
Pages1
File TypeAdobe Acrobat PDF
File Size188846
File SHA-256d9e8424eedf7e72f400dbd2fde1864d58f5b64fe4f9d5a133af98c028bca352d
PDF Metadata Authoryh
PDF Metadata ProducerAcrobat Distiller 5.0 (Windows) yh
FCC.gov SourcesFCC.gov 470161
