185018 1.8 inch 2G Bar Phone Test Setup Photos - FCC ID O55185018
FCC ID O55185018
Test setup
1.8 inch 2G Bar Phone
by SWAGTEK
Document preview loads when visible.
Document Details
| FCC ID | O55185018 |
|---|---|
| Document ID | 4237997 |
| Document Type | Test Setup Photos |
| Description | Test setup |
| Document Title | HD 271 S1 |
| Applicant | SWAGTEK |
| Equipment Class | 1.8 inch 2G Bar Phone |
| Product Code | 185018 |
| Application ID | c2YebEjcjQkzkxBQzP1p6g== |
| Application Purpose | Class II Permissive Change |
| Application Date | 2019-04-12 |
| Frequency Range | 1850.2-1909.8 MHz |
| FRN | 0021846670 |
| Test Firm | JianYan Testing Group Shenzhen Co., Ltd. |
| Certified By | Bruce Zhang EMC Laboratory Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2019-04-12 |
| Available | 2019-04-12 |
| Created | 2019-03-27 |
| Modified | 2019-03-27 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 260622 |
| File SHA-256 | 993ca59ca173a148b8a34592237d4e0653a6f6ab667372d4d48db4facb985f67 |
| PDF Metadata Author | LAB02 |
| PDF Metadata Producer | LAB02 Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 4237997 |
