503617 5.0 inch 3G Smart Phone Test Setup Photos - FCC ID O55503617
FCC ID O55503617
Test setup
5.0 inch 3G Smart Phone
by SWAGTEK
Document preview loads when visible.
Document Details
| FCC ID | O55503617 |
|---|---|
| Document ID | 4125361 |
| Document Type | Test Setup Photos |
| Description | Test setup |
| Document Title | 1 |
| Applicant | SWAGTEK |
| Equipment Class | 5.0 inch 3G Smart Phone |
| Product Code | 503617 |
| Application ID | AANmehZGFOz0o+gSyWzc/w== |
| Application Purpose | Class II Permissive Change |
| Application Date | 2019-01-01 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0021846670 |
| Test Firm | JianYan Testing Group Shenzhen Co., Ltd. |
| Certified By | Bruce Zhang EMC Laboratory Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2019-01-01 |
| Available | 2019-01-01 |
| Created | 2018-12-28 |
| Modified | 2018-12-28 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 333816 |
| File SHA-256 | 3fe5335819518b2eb5f92c93c5b4e8d58fa09679222f5ddd8b2c9fd64bc76403 |
| PDF Metadata Author | 张永岗 |
| PDF Metadata Producer | 张永岗 Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 4125361, FCC.gov 4125353 |
