554319 5.5 inch 3G Smart Phone Test Setup Photos - FCC ID O55554319
FCC ID O55554319
Test setup
5.5 inch 3G Smart Phone
by SWAGTEK
Document preview loads when visible.
Document Details
| FCC ID | O55554319 |
|---|---|
| Document ID | 4589447 |
| Document Type | Test Setup Photos |
| Description | Test setup |
| Document Title | HD 271 S1 |
| Applicant | SWAGTEK |
| Equipment Class | 5.5 inch 3G Smart Phone |
| Product Code | 554319 |
| Application ID | Xab5fBMiMzQtzevsAG85Gw== |
| Application Purpose | Original Equipment |
| Application Date | 2020-01-14 |
| FRN | 0021846670 |
| Test Firm | JianYan Testing Group Shenzhen Co., Ltd. |
| Certified By | Bruce Zhang EMC Laboratory Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2020-01-14 |
| Available | 2020-01-14 |
| Created | 2020-01-12 |
| Modified | 2020-01-12 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 398699 |
| File SHA-256 | 3be94d48b49e281b0bb14302ce3f0158ce5e0dbca8bd6a5631d917dcf58a8eae |
| PDF Metadata Author | LAB02 |
| PDF Metadata Producer | LAB02 Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 4589447 |
