X5LG28 3G Mobile Phone Test Setup Photos - FCC ID O55X5LG28
FCC ID O55X5LG28
Setup Photos
3G Mobile Phone
by SWAGTEK
Document preview loads when visible.
Document Details
| FCC ID | O55X5LG28 |
|---|---|
| Document ID | 2804413 |
| Document Type | Test Setup Photos |
| Description | Setup Photos |
| Document Title | Test Setup Photos-BT3.0 已看，标黄--已改 |
| Applicant | SWAGTEK |
| Equipment Class | 3G Mobile Phone |
| Product Code | X5LG28 |
| Application ID | wP2K6dgDdK1SL491iEeZZA== |
| Application Purpose | Original Equipment |
| Application Date | 2015-11-05 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0021846670 |
| Test Firm | Bay Area Compliance Laboratory Corp. (Shenzhen) |
| Certified By | Charles Cheng |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2015-11-05 |
| Available | 2015-11-05 |
| Created | 2017-11-13 |
| Modified | 2017-11-13 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 271346 |
| File SHA-256 | adb4a44aa296ec9cef5ae4e21dd3e5c9c8da425a47cc79028ed8462bfb54b708 |
| PDF Metadata Author | SZ151 |
| PDF Metadata Producer | GPL Ghostscript 9.18 SZ151 |
| FCC.gov Sources | FCC.gov 2804413 |
