T77W980 Gigabit RF Card Label Diagram - FCC ID O57T77W980

FCC ID O57T77W980

Label Sample and Location_R1.pdf

Gigabit RF Card

by Lenovo (Shanghai) Electronics Technology Co., Ltd

Document preview loads when visible.

Document Details

FCC IDO57T77W980
Document ID3964282
Document TypeID Label/Location Info
DescriptionLabel Sample and Location_R1.pdf
ApplicantLenovo (Shanghai) Electronics Technology Co., Ltd
Equipment ClassGigabit RF Card
Product CodeT77W980
Application ID1lVj5fKuj7xuaIuah6iXag==
Application PurposeChange in Identification
Application Date2018-08-15
Frequency Range831.5-841.5 MHz
FRN0021773460
Test FirmBureau Veritas CPS (H.K.) Ltd., Taoyuan Branch
Certified ByJoanna Hung Specialist
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date02/12/2019
Grant DeferralNo
Modular EquipmentLimited Single Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2018-08-15
Available2018-08-15
Created2018-08-14
Modified2018-08-14
Pages1
File TypeAdobe Acrobat PDF
File Size4705
File SHA-2564cc727ecf07cf2448005ef23ac83552bb4d5046ba0aeeb7c2d7acdc6c5ba110f
PDF Metadata AuthorAnnieCheng
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 3964282
