PS60XW1 VEGAPULS 69 Level Probing Radar Test... - FCC ID O6QPS60XW1

FCC ID O6QPS60XW1

15.256 Test Report R2

VEGAPULS 69 Level Probing Radar

by VEGA Grieshaber KG

Document preview loads when visible.

Document Details

FCC IDO6QPS60XW1
Document ID3407286
Document TypeTest Report
Description15.256 Test Report R2
Document TitleFCC Part 15
ApplicantVEGA Grieshaber KG
Equipment ClassVEGAPULS 69 Level Probing Radar
Product CodePS60XW1
Application IDtq9u++T0golvuqnQuHRICw==
Application PurposeClass II Permissive Change
Application Date2017-05-30
Frequency Range77000 MHz
FRN0011099314
Test FirmRhein Tech Laboratories, Inc.
Certified ByKathy Grzovic EMC Regulatory Assistant
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date11/26/2017
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2017-05-30
Available2017-05-30
Created2017-05-27
Modified2017-05-27
Pages62
File TypeAdobe Acrobat PDF
File Size2153816
File SHA-25646a8448d7341d4fd0900f3e4e302c097ad91121982acba4fda700523787e1ffd
PDF Metadata AuthorRick McMurray
PDF Metadata ProducerMicrosoft® Word 2016 Rick McMurray
FCC.gov SourcesFCC.gov 3407286
