FCC ID O6R3067
Low Power Transmitter 2402-2480 MHz
by Garmin Canada Inc.
Grantee Code: O6R Product Code: 3067
Latest application date: 2016-06-03
Device Images
FCC ID Device Details
| FCC ID | O6R3067 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | O6R |
| Product Code | 3067 |
| Applicant Business | Garmin Canada Inc. 🇨🇦 |
| Related Domains |  dynastream.com |
| Equipment Class | Low Power Transmitter 2402-2480 MHz |
| Test Firm | Rogers Labs, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-06-03 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-06-03 | PDF 1.6 MB |
| Internal Photos | Internal Photos | 2016-06-03 | PDF 153.3 KB |
| External Photos | External Photos | 2016-06-03 | PDF 68.4 KB |
| Label Sample | ID Label/Location Info | 2016-06-03 | PDF 167.5 KB |
| Block Diagram | Block Diagram | 2016-06-03 | PDF 685.2 KB |
| Test Setup Photos | Test Setup Photos | 2016-06-03 | PDF 215.8 KB |
| Test Report DXX | Test Report | 2016-06-03 | PDF 1.1 MB |
| Modular Approval Attestation Letter | Cover Letter(s) | 2016-06-03 | PDF 623 KB |
| Module Attestation Letter | Cover Letter(s) | 2016-06-03 | PDF 57.9 KB |
| Agency Authorization | Cover Letter(s) | 2016-06-03 | PDF 40.8 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-06-03 | PDF 273.7 KB |
| Schematics Metadata only | Schematics | PDF 726.7 KB | |
| Operational Description Metadata only | Operational Description | PDF 616.6 KB |
Application Information
| Application ID | YTfDbFfRxzU6O0DCytGcvg== |
|---|---|
| Final Action Date | 2016-06-03 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0008033557 |
| Model | 3067 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | Low Power Transmitter 2402-2480 MHz |
| Responsible Party | Jim Rooney, President, jim.rooney@dynastream.com , (403)932-9292 |
| Test Firm | Scot Rogers, Rogers Labs, Inc., rogers@pixius.net  , 913-837-3214 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators must be provided labeling requirements for finished products. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| YTfDbFfRxzU6O0DCytGcvg== | 2016-06-03 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 2402-2480 MHz | 15C |
Grants
TCB Grant - Application YTfDbFfRxzU6O0DCytGcvg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 06/03/2016 Application Dated: 06/03/2016 |
| Garmin Canada Inc. |
| #201, 100 Grande Blvd. |
| Cochrane, Alberta, T4C 0S4 Canada |
| Attention: Jim Rooney , President |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | O6R3067 |
| Name of Grantee: | Garmin Canada Inc. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Low Power Transmitter 2402-2480 MHz |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 |
| Single Modular Approval. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators must be provided labeling requirements for finished products. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. |
EAS Grant - Application YTfDbFfRxzU6O0DCytGcvg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Garmin Canada Inc. #201, 100 Grande Blvd. Cochrane, Alberta, T4C 0S4 Canada |
Date of Grant: 06/03/2016 Application Dated: 06/03/2016 |
| Attention: Jim Rooney , President |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | O6R3067 |
| Name of Grantee: | Garmin Canada Inc. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Low Power Transmitter 2402-2480 MHz |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 |
| Single Modular Approval. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators must be provided labeling requirements for finished products. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. |
| Mail To: |
