FCC ID O6R3153
Low Power Transmitter 2402-2480 MHz
by Garmin Canada Inc.
Grantee Code: O6R Product Code: 3153
Latest application date: 2016-11-28
Device Images
FCC ID Device Details
| FCC ID | O6R3153 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | O6R |
| Product Code | 3153 |
| Applicant Business | Garmin Canada Inc. 🇨🇦 |
| Related Domains |  dynastream.com |
| Equipment Class | Low Power Transmitter 2402-2480 MHz |
| Test Firm | Rogers Labs, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-11-28 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Install Manual | Users Manual | 2016-11-28 | PDF 1.5 MB |
| Internal Photos | Internal Photos | 2016-11-28 | PDF 742.9 KB |
| External Photos | External Photos | 2016-11-28 | PDF 698 KB |
| Label Sample | ID Label/Location Info | 2016-11-28 | PDF 162.8 KB |
| Test Setup Photos | Test Setup Photos | 2016-11-28 | PDF 947.2 KB |
| Test Report | Test Report | 2016-11-28 | PDF 1.8 MB |
| Module FCC Attestation | Cover Letter(s) | 2016-11-28 | PDF 62.4 KB |
| Agency Authorization | Cover Letter(s) | 2016-11-28 | PDF 44.4 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-11-28 | PDF 282.9 KB |
| Block Diagram Metadata only | Block Diagram | PDF 181.3 KB | |
| Schematics Metadata only | Schematics | PDF 473.1 KB | |
| Operational Description Metadata only | Operational Description | PDF 352.2 KB |
Application Information
| Application ID | vO39E5ni0bUNbOJ3+/qBow== |
|---|---|
| Final Action Date | 2016-11-28 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0008033557 |
| Model | 3153 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | Low Power Transmitter 2402-2480 MHz |
| Responsible Party | Jim Rooney, President, jim.rooney@dynastream.com , (403)932-9292 |
| Test Firm | Scot Rogers, Rogers Labs, Inc., rogers@pixius.net  , 913-837-3214 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators must be provided labeling requirements for finished products. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| vO39E5ni0bUNbOJ3+/qBow== | 2016-11-28 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 2402-2480 MHz | 15C |
Grants
TCB Grant - Application vO39E5ni0bUNbOJ3+/qBow==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 11/28/2016 Application Dated: 11/28/2016 |
| Garmin Canada Inc. |
| #201, 100 Grande Blvd. |
| Cochrane, Alberta, T4C 0S4 Canada |
| Attention: Jim Rooney , President |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | O6R3153 |
| Name of Grantee: | Garmin Canada Inc. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Low Power Transmitter 2402-2480 MHz |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 |
| Single Modular Approval. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators must be provided labeling requirements for finished products. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. |
EAS Grant - Application vO39E5ni0bUNbOJ3+/qBow==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Garmin Canada Inc. #201, 100 Grande Blvd. Cochrane, Alberta, T4C 0S4 Canada |
Date of Grant: 11/28/2016 Application Dated: 11/28/2016 |
| Attention: Jim Rooney , President |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | O6R3153 |
| Name of Grantee: | Garmin Canada Inc. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Low Power Transmitter 2402-2480 MHz |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 |
| Single Modular Approval. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators must be provided labeling requirements for finished products. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. |
