1178 UHF Pocsag Paging Transmitter Schematics - FCC ID O871178
FCC ID O871178
Block Diagram 1178
UHF Pocsag Paging Transmitter
Document preview loads when visible.
Document Details
| FCC ID | O871178 |
|---|---|
| Document ID | 177619 |
| Document Type | Schematics |
| Description | Block Diagram 1178 |
| Document Title | RFFlow - 1178.PDF |
| Applicant | Sea Air and Land Communications |
| Equipment Class | UHF Pocsag Paging Transmitter |
| Product Code | 1178 |
| Application ID | 9Nd9mbxH1f6CChU2ZlLA0A== |
| Application Purpose | Original Equipment |
| Application Date | 2001-11-09 |
| Frequency Range | 450-470 MHz |
| FRN | 0003783677 |
| Test Firm | EMC Technologies NZ Ltd. |
| Certified By | Andrew Cutler General Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2001-11-05 |
| Available | 2001-11-09 |
| Created | 2001-11-05 |
| Modified | 2001-11-05 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 4294 |
| File SHA-256 | 449c7cf1754902c08c172300f1c2aed61f2b7e2b4d9e8ad5ca45c2147c3376d8 |
| PDF Metadata Author | MurrayE |
| PDF Metadata Producer | RFFlow - 1178.FLO Acrobat PDFWriter 4.05 for Windows NT |
| FCC.gov Sources | FCC.gov 177619 |
