TX315 Remote Control Transmitter Schematics - FCC ID OAVTX315

FCC ID OAVTX315

Schematic Diagram

Remote Control Transmitter

by Altrusty Enterprise Co Ltd

Document preview loads when visible.

Document Details

FCC IDOAVTX315
Document ID149405
Document TypeSchematics
DescriptionSchematic Diagram
ApplicantAltrusty Enterprise Co Ltd
Equipment ClassRemote Control Transmitter
Product CodeTX315
Application IDelo6MRy+/fJQ/Qhcn5wNHQ==
Application PurposeOriginal Equipment
Application Date2001-05-11
Frequency Range315 MHz
FRN0007607864
Test FirmCompliance Engineering Services
Certified ByRick Yeo EMC Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2001-05-11
Available2001-05-11
Created2001-04-18
Modified2001-04-18
Pages1
File TypeAdobe Acrobat PDF
File Size57441
File SHA-2562b8ee0b19b48b02b9e1e42ffac32f70e44dd5cd8ebb011d36ead599e06d46529
PDF Metadata ProducerAcrobat Distiller 4.0 for Windows
FCC.gov SourcesFCC.gov 149405
