ALPHA1930 Pager Schematics - FCC ID OBMALPHA-1-930

FCC ID OBMALPHA-1-930

Circuit Diagram

Pager

by VTech Connect Limited

Document preview loads when visible.

Document Details

FCC IDOBMALPHA-1-930
Document ID39214
Document TypeSchematics
DescriptionCircuit Diagram
Document TitlePADS Postscript Driver Header
ApplicantVTech Connect Limited
Equipment ClassPager
Product CodeALPHA1930
Application IDR5akTibZOcPuI/zVQlGTQQ==
Application PurposeOriginal Equipment
Application Date1999-06-30
Frequency Range928-932 MHz
FRN0021823992
Test FirmIntertek Testing Services Hong Kong
Certified ByWILBUR NG ASSISTANT MANAGER/ETL SEMKO
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted1999-05-28
Available1999-06-30
Created1999-05-14
Modified1999-05-14
Pages1
File TypeAdobe Acrobat PDF
File Size80679
File SHA-256d953fa2676f205c545aa7be6b83e7b7e7b5ffe9e298bf558a596eec57ebda1d9
PDF Metadata AuthorCAD Software, Littleton, MA
PDF Metadata ProducerAcrobat Distiller 3.0 for Windows Andy Montalvo, 18 Lupine St., Lowell, MA 01851
FCC.gov SourcesFCC.gov 39214
