HWS3 Optical wireless gaming headset Teardown... - FCC ID ODCHW-S3

FCC ID ODCHW-S3

int photos

Optical wireless gaming headset

by Shenzhen Bada Sheng Electronic Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDODCHW-S3
Document ID3524662
Document TypeInternal Photos
Descriptionint photos
ApplicantShenzhen Bada Sheng Electronic Co., Ltd.
Equipment ClassOptical wireless gaming headset
Product CodeHWS3
Application ID3RW8VL/iHyfxQ63md0etMw==
Application PurposeOriginal Equipment
Application Date2017-08-24
Frequency Range2403-2478 MHz
FRN0021838420
Test FirmDongguan Precise Testing Service Co., Ltd.
Certified ByWonderful Wang
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2017-08-24
Available2017-08-24
Created2017-08-02
Modified2017-08-02
Pages2
File TypeAdobe Acrobat PDF
File Size420184
File SHA-256ec01cebf4cd73752f3ab2de704f099213dd83ee2e5716031e53c01105dd2c05e
PDF Metadata AuthorAdministrator
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 3524662, FCC.gov 3524636
