12429TX49 R/C POWER BOSS Block Diagram - FCC ID OGM12429TX-49

FCC ID OGM12429TX-49

BLOCK DIAGRAM

R/C POWER BOSS

by Enertec Enterprises Ltd.

Document preview loads when visible.

Document Details

FCC IDOGM12429TX-49
Document ID712994
Document TypeBlock Diagram
DescriptionBLOCK DIAGRAM
ApplicantEnertec Enterprises Ltd.
Equipment ClassR/C POWER BOSS
Product Code12429TX49
Application IDk2GYeGpgpD04r4Xn2sI9Og==
Application PurposeOriginal Equipment
Application Date2006-10-06
Frequency Range49.86 MHz
FRN0006108070
Test FirmCMA Industrial Development Foundations Limited
Certified ByANDY CHAN ENGINEER
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2006-10-06
Available2006-10-06
Created2006-10-05
Modified2006-10-05
Pages1
File TypeAdobe Acrobat PDF
File Size19634
File SHA-25619bc4c79121ea9756d8fdd5adf9f761f926ccaad2c0f68eda019c86b5bf35c72
FCC.gov SourcesFCC.gov 712994
