Document Details
| FCC ID | OH2500RU |
|---|---|
| Document ID | 29418 |
| Document Type | External Photos |
| Description | Side view |
| Applicant | Medtronic MiniMed, Inc. |
| Equipment Class | 500RU |
| Product Code | 500RU |
| Application ID | T0/Q1Fv1H8dII6lQa8nL/g== |
| Application Purpose | Original Equipment |
| Application Date | 1999-05-03 |
| Frequency Range | 418 MHz |
| FRN | 0006729248 |
| Test Firm | CKC Laboratories, Inc. |
| Certified By | Tracy Phillips |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 1999-03-29 |
| Available | 1999-05-03 |
| Pages | 0 |
| File Type | JPEG Image |
| File Size | 153485 |
| File SHA-256 | 0ad6d1e64c2e535ea8c8d93fc32bd8ee27fa53bf38276f01654429ca8a809d8d |
| FCC.gov Sources | FCC.gov 29418 |
