ELM1700S LCD Monitor Teardown Internal Photos - FCC ID OIOELM-1700S

FCC ID OIOELM-1700S

Internal Photos

LCD Monitor

by E-RAE Electronics Industry Co Ltd

Document preview loads when visible.

Document Details

FCC IDOIOELM-1700S
Document ID668050
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleAppendix-D Internal Photosl_DS-1700S
ApplicantE-RAE Electronics Industry Co Ltd
Equipment ClassLCD Monitor
Product CodeELM1700S
Application ID2hGRsGlwRxJiXb0pDsikHg==
Application PurposeOriginal Equipment
Application Date2006-06-13
FRN0007653710
Test FirmE-RAE Testing Laboratory
Certified ByYo Han, Park Chief Engineer of EMC Team (Agent)
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2006-06-13
Available2006-06-13
Created2006-06-13
Modified2006-06-13
Pages16
File TypeAdobe Acrobat PDF
File Size2221412
File SHA-25674d27d9a0ffa4e80bf6f978ddd01612e5629b901c2a2e37f157aef0e474033d2
PDF Metadata Authoryhyoon
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows) yhyoon
FCC.gov SourcesFCC.gov 668050
