FCC ID OJFGXCPLA3
GX 40W Quad-BAnd Remote Unit
by Corning Optical Communication LLC
Grantee Code: OJF Product Code: GXCPLA3
Latest application date: 2016-12-21
Device Images
FCC ID Device Details
| FCC ID | OJFGXCPLA3 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | OJF |
| Product Code | GXCPLA3 |
| Applicant Business | Corning Optical Communication LLC 🇺🇸 |
| Related Domains |  corning.com  sgs.com |
| Equipment Class | GX 40W Quad-BAnd Remote Unit |
| Test Firm | SGS-CSTC Standards Technical Services Co., Ltd |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 728-757 MHz | Original Equipment | 2016-12-21 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| user manual | Users Manual | 2016-12-21 | PDF 2 MB |
| Internal photos | Internal Photos | 2016-12-21 | PDF 1.3 MB |
| External photos | External Photos | 2016-12-21 | PDF 207.2 KB |
| Label Location | ID Label/Location Info | 2016-12-21 | PDF 180.7 KB |
| Set up Photos | Test Setup Photos | 2016-12-21 | PDF 119.7 KB |
| Test Report 1 | Test Report | 2016-12-21 | PDF 5.7 MB |
| Test Report 2 | Test Report | 2016-12-21 | PDF 5.3 MB |
| Test Report 3 | Test Report | 2016-12-21 | PDF 4.5 MB |
| Antenna Info | Attestation Statements | 2016-12-21 | PDF 164 KB |
| Declaration Letter | Attestation Statements | 2016-12-21 | PDF 216.1 KB |
| Authorization Letter | Cover Letter(s) | 2016-12-21 | PDF 236.2 KB |
| Confidentiality letter | Cover Letter(s) | 2016-12-21 | PDF 11.7 KB |
| RF Exposure Info | RF Exposure Info | 2016-12-21 | PDF 83.3 KB |
| Block Diagram Metadata only | Block Diagram | PDF 23.9 KB | |
| Schematics Metadata only | Schematics | PDF 1.6 MB | |
| Operational Description Metadata only | Operational Description | PDF 484.8 KB | |
| BOM for AC Metadata only | Parts List/Tune Up Info | PDF 170 KB | |
| BOM for DC Metadata only | Parts List/Tune Up Info | PDF 170.1 KB | |
| Tune Up Metadata only | Parts List/Tune Up Info | PDF 623.8 KB |
Application Information
| Application ID | KtAsMnkewRmSaQ808jdSzA== |
|---|---|
| Final Action Date | 2016-12-21 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0017154329 |
| Model | GXCPLA3 |
| Frequency Range | 728-757 MHz |
| Equipment Class | B2I - Part 20 Industrial Booster (CMRS) |
| Device Description | GX 40W Quad-BAnd Remote Unit |
| Responsible Party | Jyotin Basrur, Senior Director, Product Line Management, basrurj@corning.com , 817-431-7894 |
| Agent | Kobe Kobe Kobe, SGS-CSTS Standards Technical Services Co., Ltd, kobe.jian@sgs.com , 86-0-21-6191-5664 |
| Technical Contact | Kobe Jian, SGS-CSTS Standards Technical Services Co., kobe.jian@sgs.com , 86 20 8215 5314 |
| Non-Technical Contact | Rita Zhao, SGS-CSTS Standards Technical Services Co., rita.zhao@sgs.com , 86-20-8215-5455 |
| Test Firm | Jerry Chan, SGS-CSTC Standards Technical Services Co., Ltd, Jerry.Chan@sgs.com , 860-208215-5331 |
| TCB Email | uscts.tcb@sgs.com |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. Power listed is per carrier. Emission designator F9W covers both CDMA and WCDMA. This transmitter operates as a remote unit as part of a system along with master unit components as described in this filing, and excluding any other devices connected to the (downlink) output terminal of the master unit. This application covers only the system configuration with master unit connected to a base station in downlink path; operations if any with master unit connected to antenna or amplifier in the downlink require separate equipment authorization. Antenna installed for each remote unit must provide a minimum 1.6 m separation distance from all persons as described in this filling. The antenna(s) used for the transmitter must be fixed-mounted on output permanent structures with maximum permissive gain of external antenna up to 12.5 dBi. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC bureau(s), including antenna co-location requirement of 1.1307(b)(3). |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| KtAsMnkewRmSaQ808jdSzA== | 2016-12-21 | Original Equipment |
Equipment Authorization
| Frequency | Output | Emission | Rules |
|---|---|---|---|
| 862-869 MHz | 46.773 | F9W | 90S |
| 862-869 MHz | 45.708 | F9W | 90S |
| 862-869 MHz | 43.651 | G7D | 90S |
| 869-894 MHz | 45.708 | GXW | 22H |
| 869-894 MHz | 45.708 | F9W | 22H |
| 869-894 MHz | 46.773 | F9W | 22H |
| 869-894 MHz | 44.668 | G7D | 22H |
| 1930-1995 MHz | 46.773 | F9W | 24E |
| 1930-1995 MHz | 47.863 | F9W | 24E |
| 1930-1995 MHz | 46.773 | G7D | 24E |
| 1930-1995 MHz | 50.118 | GXW | 24E |
| 2110-2180 MHz | 44.668 | F9W | 27 |
| 2110-2180 MHz | 43.651 | G7D | 27 |
Grants
TCB Grant - Application KtAsMnkewRmSaQ808jdSzA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
SGS North America, Inc. 620 Old Peachtree Road NW Suite 100 Suwanee, GA 30024 |
Date of Grant: 12/21/2016 Application Dated: 12/21/2016 |
| Corning Optical Communication LLC |
| 6 Concord Road |
| Shrewsbury, MA 01545 |
| Attention: Jyotin Basrur , Senior Director, Product Line Management |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | OJFGXCPLA3 |
| Name of Grantee: | Corning Optical Communication LLC |
| Equipment Class: | Part 20 Industrial Booster (CMRS) |
| Notes: | GX 40W Quad-BAnd Remote Unit |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 27 | 728.0 - 757.0 | 42.657 | G7D | ||
| 90S | 862.0 - 869.0 | 46.773 | F9W | ||
| 90S | 862.0 - 869.0 | 45.708 | F9W | ||
| 90S | 862.0 - 869.0 | 43.651 | G7D | ||
| 22H | 869.0 - 894.0 | 45.708 | GXW | ||
| 22H | 869.0 - 894.0 | 45.708 | F9W | ||
| 22H | 869.0 - 894.0 | 46.773 | F9W | ||
| 22H | 869.0 - 894.0 | 44.668 | G7D | ||
| 24E | 1930.0 - 1995.0 | 50.118 | GXW | ||
| 24E | 1930.0 - 1995.0 | 46.773 | F9W | ||
| 24E | 1930.0 - 1995.0 | 47.863 | F9W | ||
| 24E | 1930.0 - 1995.0 | 46.773 | G7D | ||
| 27 | 2110.0 - 2180.0 | 44.668 | F9W | ||
| 27 | 2110.0 - 2180.0 | 43.651 | G7D |
| Power listed is conducted. Power listed is per carrier. Emission designator F9W covers both CDMA and WCDMA. This transmitter operates as a remote unit as part of a system along with master unit components as described in this filing, and excluding any other devices connected to the (downlink) output terminal of the master unit. This application covers only the system configuration with master unit connected to a base station in downlink path; operations if any with master unit connected to antenna or amplifier in the downlink require separate equipment authorization. Antenna installed for each remote unit must provide a minimum 1.6 m separation distance from all persons as described in this filling. The antenna(s) used for the transmitter must be fixed-mounted on output permanent structures with maximum permissive gain of external antenna up to 12.5 dBi. RF exposure compliance is addressed at the time of licensing, as required by the responsible FCC bureau(s), including antenna co-location requirement of 1.1307(b)(3). |
