1. FCC ID
  2. OJI
  3. OJI-81000TXA
  4. Circuit diagram

81000TXA Remote Control NASCAR Schematics - FCC ID OJI-81000TXA

FCC ID OJI-81000TXA

Circuit diagram

Remote Control NASCAR

by Racing Champions Ltd.

Document preview loads when visible.

Document Details

FCC IDOJI-81000TXA
Document ID38495
Document TypeSchematics
DescriptionCircuit diagram
ApplicantRacing Champions Ltd.
Equipment ClassRemote Control NASCAR
Product Code81000TXA
Application IDd2Y/RqTehn0tDjyDRjqTBg==
Application PurposeOriginal Equipment
Application Date1999-06-30
Frequency Range27.145 MHz
FRN9999999999
Test FirmIntertek Testing Services Hong Kong
Certified ByC. K. Lam Technical Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted1999-05-24
Available1999-06-30
Created1999-05-18
Modified1999-05-18
Pages1
File TypeAdobe Acrobat PDF
File Size48464
File SHA-256b36d359d4e8b9962c8af9c49b7407ae3500f78fe559c5c658deea192453d3c71
PDF Metadata ProducerAcrobat 3.0 Scan Plug-in Acrobat 3.0 Scan Plug-in
FCC.gov SourcesFCC.gov 38495
