BS2708DB STEREO Teardown Internal Photos - FCC ID OKUBS2708DB

FCC ID OKUBS2708DB

Internal photo

STEREO

by Shenzhen Junlan Electronic Ltd

Document preview loads when visible.

Document Details

FCC IDOKUBS2708DB
Document ID9225763
Document TypeInternal Photos
DescriptionInternal photo
ApplicantShenzhen Junlan Electronic Ltd
Equipment ClassSTEREO
Product CodeBS2708DB
Application IDs6I6DCid5K71x+QFoYJL9A==
Application PurposeOriginal Equipment
Application Date2026-04-17
Frequency Range2402-2480 MHz
FRN0021880893
Test FirmGuangdong Asia Hongke Test Technology Limited
Certified ByYouk Chen safety engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Modular EquipmentDoes not apply
Composite DeviceYes
Submitted2026-04-17
Available2026-04-17
Created2026-04-14
Modified2026-04-14
Pages4
File TypeAdobe Acrobat PDF
File Size1224618
File SHA-256c4b2f09c536794b3900e5b1aba3124ee1eb2c59e35d3e376db76d32931d7dbff
PDF Metadata ProducerMicrosoft? Word 2016 Microsoft? Word 2016
FCC.gov SourcesFCC.gov 9225763, FCC.gov 9224670
