T60TX08 SECURITY TRANSMITTER Block Diagram - FCC ID ONFT60TX-08
FCC ID ONFT60TX-08
BLOCK DIAGRAM
SECURITY TRANSMITTER
Document preview loads when visible.
Document Details
| FCC ID | ONFT60TX-08 |
|---|---|
| Document ID | 376045 |
| Document Type | Block Diagram |
| Description | BLOCK DIAGRAM |
| Document Title | 1 |
| Applicant | Tele Radio AB |
| Equipment Class | SECURITY TRANSMITTER |
| Product Code | T60TX08 |
| Application ID | EEcs1UhaaiC3/j3z64jsRA== |
| Application Purpose | Original Equipment |
| Application Date | 2003-11-25 |
| Frequency Range | 433-434 MHz |
| FRN | 0008300451 |
| Test Firm | Timco Engineering, Inc. |
| Certified By | MARTIN OSTERMAN |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2003-11-25 |
| Available | 2003-11-25 |
| Created | 2003-11-25 |
| Modified | 2003-11-25 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 5258 |
| File SHA-256 | 558a21c0e28bee33a616488c1e2aa48656a97f425912a7cc93b243bb95c44911 |
| PDF Metadata Author | erin |
| PDF Metadata Producer | Acrobat Distiller 4.05 for Windows Microsoft Word 9.0 |
| FCC.gov Sources | FCC.gov 376045 |
