K1801U Wireless Keyboard Block Diagram - FCC ID OO9K1801U

FCC ID OO9K1801U

Block Diagram

Wireless Keyboard

by G.Tech Technology Ltd.

Document preview loads when visible.

Document Details

FCC IDOO9K1801U
Document ID416772
Document TypeBlock Diagram
DescriptionBlock Diagram
ApplicantG.Tech Technology Ltd.
Equipment ClassWireless Keyboard
Product CodeK1801U
Application IDmIb+42flToNGkqQpSz4K4Q==
Application PurposeOriginal Equipment
Application Date2004-04-21
Frequency Range26.96-27.28 MHz
FRN0009193962
Test FirmBay Area Compliance Laboratory
Certified ByRex Lai
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-04-22
Available2004-04-21
Created2004-02-06
Modified2004-02-06
Pages1
File TypeAdobe Acrobat PDF
File Size5822
File SHA-256121eb7aafbe265079c082200a816e59e6ff6dbe044b249f00e4ee951113da9de
PDF Metadata AuthorZyy
PDF Metadata Producerhttp://www.fineprint.com FinePrint pdfFactory v1.23 (Windows XP Chinese)
FCC.gov SourcesFCC.gov 416772
