PTM1000 (TRA 1000S, FE, 1.4, 28GHz [S1])

by Wavtrace, Inc.

Bottom

Document Details

FCC IDOPU-PTM1000-28
Document ID59410
Document TypeExternal Photos
DescriptionBottom
ApplicantWavtrace, Inc.
Equipment ClassPTM1000 (TRA 1000S, FE, 1.4, 28GHz [S1])
Product CodePTM100028
Application IDG4q3MFQNXuSlml8ILNwNqw==
Application PurposeOriginal Equipment
Application Date2000-01-31
Frequency Range27512.5-28337.5 MHz
FRN9999999999
Test FirmCKC Laboratories, Inc.
Certified ByTracy Phillips Documentation Control Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted1999-09-17
Available2000-01-31
Pages0
File TypeJPEG Image
File Size39389
File SHA-256e8c30e0edcc49b84803f4feb222906df8059ea596cc6ecdcbdb996acff093ff6
FCC.gov SourcesFCC.gov 59410
