CHUNGS05004 Wireless Weather Station... - FCC ID OQH-CHUNGS-05-004

FCC ID OQH-CHUNGS-05-004

Block Diagram

Wireless Weather Station (Receiver)

by Chung's Electronic Co. Ltd.

Document preview loads when visible.

Document Details

FCC IDOQH-CHUNGS-05-004
Document ID576285
Document TypeBlock Diagram
DescriptionBlock Diagram
Document Title8154 BLOCK DIARRAM
ApplicantChung's Electronic Co. Ltd.
Equipment ClassWireless Weather Station (Receiver)
Product CodeCHUNGS05004
Application IDt/Q8ttNIhVM9CxtcyqSxbw==
Application PurposeOriginal Equipment
Application Date2005-08-30
Frequency Range433.92 MHz
FRN0017878992
Test FirmIntertek Testing Services Hong Kong
Certified ByDerek Leung Assistant Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2005-08-30
Available2005-08-30
Created2005-04-28
Modified2005-06-10
Pages1
File TypeAdobe Acrobat PDF
File Size44855
File SHA-256ccd5e967e5ebb74cc8fa39edd20a174ee992bbec24c4ee739e1e65c425379bce
PDF Metadata Authorchan
PDF Metadata Producerchan Acrobat PDFWriter 5.0 for Windows
FCC.gov SourcesFCC.gov 576285
