IBT0602S Bluetooth Module Test Setup Photos - FCC ID ORP-IBT0602S

FCC ID ORP-IBT0602S

Test Setup photos

Bluetooth Module

by ValenceTech Limited

Document preview loads when visible.

Document Details

FCC IDORP-IBT0602S
Document ID2193363
Document TypeTest Setup Photos
DescriptionTest Setup photos
Document TitleiBT-06-02S_Test Setup Photos
ApplicantValenceTech Limited
Equipment ClassBluetooth Module
Product CodeIBT0602S
Application ID/AHxDQhaJp1/+LADa9STjA==
Application PurposeOriginal Equipment
Application Date2014-02-19
Frequency Range2402-2480 MHz
FRN0021912209
Test FirmAttestation of Global Compliance Shenzhen Co. Ltd.
Certified ByH.W. Poon
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2014-02-19
Available2014-02-19
Created2014-02-18
Modified2014-02-18
Pages1
File TypeAdobe Acrobat PDF
File Size1026465
File SHA-256ffb51e12736e4c1a24421b3387ec5e602e02da59922e9cee25d34e421aff892d
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows) Administrator
FCC.gov SourcesFCC.gov 2193363
