74045R49 MXS RC Asst. #3 - MXS 49MHz Block... - FCC ID OTA74045R49

FCC ID OTA74045R49

block diagram

MXS RC Asst. #3 - MXS 49MHz

by Jakks Pacific (HK) Ltd.

Document preview loads when visible.

Document Details

FCC IDOTA74045R49
Document ID1512326
Document TypeBlock Diagram
Descriptionblock diagram
Document Titleblock
ApplicantJakks Pacific (HK) Ltd.
Equipment ClassMXS RC Asst. #3 - MXS 49MHz
Product Code74045R49
Application IDwDtPZjhRuesb4/Odqfybkw==
Application PurposeOriginal Equipment
Application Date2011-07-29
Frequency Range49.86 MHz
FRN0014191258
Test FirmIntertek Testing Services Hong Kong Ltd.
Certified ByTerry Chan Assistant Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2011-07-29
Available2011-07-29
Created2011-04-06
Modified2011-07-13
Pages1
File TypeAdobe Acrobat PDF
File Size257023
File SHA-256ffe0e5d8118da8dfbd60de57d410b6ba739e7724c5a40b8ebfb7e63fb7802e71
PDF Metadata Authorandy.yan
PDF Metadata CreatorPDFCreator Version 0.9.9
PDF Metadata ProducerGPL Ghostscript 8.70
FCC.gov SourcesFCC.gov 1512326
