FCC ID OTA77228TX
Test setup photos.pdf
Black Panther RC Stealth Cruiser
Document preview loads when visible.
Document Details
| FCC ID | OTA77228TX |
|---|---|
| Document ID | 3670938 |
| Document Type | Test Setup Photos |
| Description | Test setup photos.pdf |
| Document Title | 171102N025-2 (remote) Test photos |
| Applicant | Jakks Pacific (HK) Ltd. |
| Equipment Class | Black Panther RC Stealth Cruiser |
| Product Code | 77228TX |
| Application ID | LSVhFMb3ByDXMUwABF4OxA== |
| Application Purpose | Original Equipment |
| Application Date | 2017-12-11 |
| Frequency Range | 2408-2440 MHz |
| FRN | 0014191258 |
| Test Firm | Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch |
| Certified By | Tsz Man Sze Senior Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Submitted | 2017-12-11 |
| Available | 2017-12-11 |
| Created | 2017-12-08 |
| Modified | 2017-12-08 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 276845 |
| File SHA-256 | b5e7c2ce3bcd0d6bc0c6ff33394e1df7ff14d11ec5755fae4c193f05420e4457 |
| PDF Metadata Author | glyhe |
| PDF Metadata Producer | GPL Ghostscript 9.10; modified using iTextSharp 5.2.1 (c) 1T3XT BVBA glyhe |
| FCC.gov Sources | FCC.gov 3670938 |
