843911927MTX R/C Mini Frip Block Diagram - FCC ID OTM-8439119-27MTX

FCC ID OTM-8439119-27MTX

Block

R/C Mini Frip

by KIDZTECH TOYS MANUFACTURING LTD

Document preview loads when visible.

Document Details

FCC IDOTM-8439119-27MTX
Document ID4292373
Document TypeBlock Diagram
DescriptionBlock
Document Title84181 TX CBA
ApplicantKIDZTECH TOYS MANUFACTURING LTD
Equipment ClassR/C Mini Frip
Product Code843911927MTX
Application IDbAzel6nnVv0s3wEpC3XrnQ==
Application PurposeOriginal Equipment
Application Date2019-05-24
Frequency Range27.145 MHz
FRN0021921747
Test FirmIntertek Testing Services Hong Kong Ltd.
Certified ByTerry Chan Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2019-05-24
Available2019-05-24
Created2019-05-02
Modified2019-05-02
Pages1
File TypeAdobe Acrobat PDF
File Size51578
File SHA-2567bf6d022f5393ca929aad4eaff849ed477f53d82e9e02f64429bffaa86f3b4bf
PDF Metadata AuthorWindows 9x/NT/2000/XP User
PDF Metadata CreatorAdobe Illustrator CC (Windows)
PDF Metadata ProducerAcrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 4292373
