883161749MRX FL 1/12 Street Racers (2... - FCC ID OTM-8831617-49MRX

FCC ID OTM-8831617-49MRX

Circuit Diagram

FL 1/12 Street Racers (2 Asst) / FL 1/12 Lamborghini Veneno, FL 1/12 Bugatti, 1/12 RC Cars

by KIDZTECH TOYS MANUFACTURING LTD

Document preview loads when visible.

Document Details

FCC IDOTM-8831617-49MRX
Document ID3458585
Document TypeSchematics
DescriptionCircuit Diagram
Document TitleNo Title
ApplicantKIDZTECH TOYS MANUFACTURING LTD
Equipment ClassFL 1/12 Street Racers (2 Asst) / FL 1/12 Lamborghini Veneno, FL 1/12 Bugatti, 1/12 RC Cars
Product Code883161749MRX
Application IDonRfwoZXJoq2VxRUWaZ9Bw==
Application PurposeOriginal Equipment
Application Date2017-07-10
Frequency Range49.86 MHz
FRN0021921747
Test FirmIntertek Testing Services Hong Kong Ltd.
Certified ByTerry Chan Assistant Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2017-07-10
Available2017-07-10
Created2015-11-12
Modified2017-07-04
Pages1
File TypeAdobe Acrobat PDF
File Size94607
File SHA-25640c1a32435e404de327cf44daff15cda40f2d7b4acf9c22590a67daa907dde28
PDF Metadata AuthorWindows 9x/NT/2000/XP User
PDF Metadata ProducerWindows 9x/NT/2000/XP User llPDFLib 3.x
FCC.gov SourcesFCC.gov 3458585
