XH9RX Receiver for water timer Teardown... - FCC ID OVWXH9-RX

FCC ID OVWXH9-RX

internal photo

Receiver for water timer

by Bondrich Development Limited

internal photo

Document Details

FCC IDOVWXH9-RX
Document ID144134
Document TypeInternal Photos
Descriptioninternal photo
ApplicantBondrich Development Limited
Equipment ClassReceiver for water timer
Product CodeXH9RX
Application IDsLESygaNaju7989a5G+0Yg==
Application PurposeOriginal Equipment
Application Date2001-04-10
Frequency Range315 MHz
FRN9999999999
Test FirmIntertek Testing Services Hong Kong
Certified ByWilson Loke Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2001-04-10
Available2001-04-10
Pages0
File TypeJPEG Image
File Size54906
File SHA-256a49f98c538f62bd2c9e657b258383eac0f4df0e08070e4a76e1cce718abb0af6
FCC.gov SourcesFCC.gov 144134, FCC.gov 144138, FCC.gov 144135, FCC.gov 144133
