TX0271451003 Spider-Action Quad Block... - FCC ID OYK-TX027145-1003

FCC ID OYK-TX027145-1003

Block Diagram

Spider-Action Quad

by Silverlit Toys Manufactory Ltd.

Document preview loads when visible.

Document Details

FCC IDOYK-TX027145-1003
Document ID1317328
Document TypeBlock Diagram
DescriptionBlock Diagram
Document TitleSL-10-TX 27MHZ
ApplicantSilverlit Toys Manufactory Ltd.
Equipment ClassSpider-Action Quad
Product CodeTX0271451003
Application IDmfo9gCDYxltN6FJe73/8Ow==
Application PurposeOriginal Equipment
Application Date2010-07-25
Frequency Range27.145 MHz
FRN0018442582
Test FirmIntertek Testing Services Hong Kong Ltd.
Certified ByBen Ho Senior Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2010-07-25
Available2010-07-25
Created2010-07-22
Modified2010-07-23
Pages2
File TypeAdobe Acrobat PDF
File Size133947
File SHA-2565222853eecc91d5ba06992edfde67f6bb821350d8f5f40915fcaa823bb6b5906
PDF Metadata AuthorAdministrator
PDF Metadata CreatorPScript5.dll Version 5.2
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows)
FCC.gov SourcesFCC.gov 1317328
