AMP11240BTS Test Report - FCC ID OZMAMP11240BTS

FCC ID OZMAMP11240BTS

pwrout

AMP11240BTS

by Amplidyne Inc.

Document preview loads when visible.

Document Details

FCC IDOZMAMP11240BTS
Document ID159002
Document TypeTest Report
Descriptionpwrout
Document Titletabular2.PDF
ApplicantAmplidyne Inc.
Equipment ClassAMP11240BTS
Product CodeAMP11240BTS
Application ID6rftTEp74uBsDzSoLSROdw==
Application PurposeOriginal Equipment
Application Date2001-10-17
Frequency Range2412-2462 MHz
FRN9999999999
Test FirmRetlif Testing Laboratories
Certified ByThomas J. Schneider EMC Test Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2001-07-10
Available2001-10-17
Created2001-07-10
Modified2001-07-10
Pages1
File TypeAdobe Acrobat PDF
File Size7821
File SHA-256a67e71aad50c00ebd6ff5933fc8b284c788313ec165ead0ee4ee2b6c38279489
PDF Metadata Producertabular2.ftw Acrobat PDFWriter 4.0 for Windows
