HEMC8256A2501R Remotre Control for... - FCC ID P25HEMC8256A2501R

FCC ID P25HEMC8256A2501R

I Photo 1 PCB Comp Side

Remotre Control for Playstation 2

by Mad Catz, Inc.

I Photo 1 PCB Comp Side

Document Details

FCC IDP25HEMC8256A2501R
Document ID183542
Document TypeInternal Photos
DescriptionI Photo 1 PCB Comp Side
ApplicantMad Catz, Inc.
Equipment ClassRemotre Control for Playstation 2
Product CodeHEMC8256A2501R
Application IDXILxlu4s2qZLXVGr1YqT1Q==
Application PurposeOriginal Equipment
Application Date2001-12-14
Frequency Range902.2 MHz
FRN0007458433
Test FirmIntertek Testing Services Hong Kong
Certified ByWilbur Ng Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2001-12-14
Available2001-12-14
Pages0
File TypeJPEG Image
File Size199643
File SHA-25673d9e797b8a785bdaee783e1f99ac86d12ab0409d3cf1ddfd9b1ef266bfa2af4
FCC.gov SourcesFCC.gov 183542
