FCC ID P4H-ICHNDHLD
IntelliCenter Wireless Remote Control
by Pentair Aquatic Systems
Grantee Code: P4H Product Code: ICHNDHLD
Latest application date: 2017-04-18
Device Images
FCC ID Device Details
| FCC ID | P4H-ICHNDHLD |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | P4H |
| Product Code | ICHNDHLD |
| Applicant Business | Pentair Aquatic Systems 🇺🇸 |
| Related Domains |  pentair.com |
| Equipment Class | IntelliCenter Wireless Remote Control |
| Test Firm | Laird Connectivity, Inc |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2475 MHz | Original Equipment | 2017-04-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual 041217 | Users Manual | 2017-04-18 | PDF 3.5 MB |
| Internal Photos | Internal Photos | 2017-04-18 | PDF 873.9 KB |
| External Photos | External Photos | 2017-04-18 | PDF 918.9 KB |
| External Label | ID Label/Location Info | 2017-04-18 | PDF 458.6 KB |
| Label Locations | ID Label/Location Info | 2017-04-18 | PDF 1.1 MB |
| Label Under Battery | ID Label/Location Info | 2017-04-18 | PDF 442.3 KB |
| Test Photos | Test Setup Photos | 2017-04-18 | PDF 470.5 KB |
| Test Report V 2b | Test Report | 2017-04-18 | PDF 4.4 MB |
| Agency Letter | Cover Letter(s) | 2017-04-18 | PDF 38.3 KB |
| Confidentiality Letter | Cover Letter(s) | 2017-04-18 | PDF 37.6 KB |
| RF Exposure Rev B | RF Exposure Info | 2017-04-18 | PDF 2 MB |
| Block Diagram Revised Metadata only | Block Diagram | PDF 195.9 KB | |
| Schematics Metadata only | Schematics | PDF 3 MB | |
| Operational Description Metadata only | Operational Description | PDF 103.1 KB |
Application Information
| Application ID | bi8x4iACzrxeaQTM5r/4aQ== |
|---|---|
| Final Action Date | 2017-04-18 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0005870969 |
| Model | ICHNDHLD |
| Frequency Range | 2405-2475 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | IntelliCenter Wireless Remote Control |
| Responsible Party | Edward Feten, Senior Electrical Engineer -- NPD/Automation, edward.feten@pentair.com , 805-553-5475 |
| Agent | Thomas Thomas Thomas, LS Research, LLC, tom.smith@lairdtech.com  , 2624214986 |
| Technical Contact | Edward Feten, Pentair Aquatic Systems, edward.feten@pentair.com , 805-553-5475 |
| Test Firm | Adam Alger, Laird Connectivity, Inc, adam.alger@lairdconnect.com  , 262 375 3091 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output is RF conducted. Power output is reduced at band edge channels as addressed in the filing. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedure. Grantee must provide installation and operating instructions for complying with FCC multi-transmitter product procedures and RF Exposure compliance. The highest reported SAR is 0.88 W/kg. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| bi8x4iACzrxeaQTM5r/4aQ== | 2017-04-18 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2405-2475 MHz | 0.1140000 | 15C |
Grants
TCB Grant - Application bi8x4iACzrxeaQTM5r/4aQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 04/18/2017 Application Dated: 04/18/2017 |
| Pentair Aquatic Systems |
| 10951 W. Los Angeles Ave. |
| Moorpark, CA 93021 |
| Attention: Edward Feten , Senior Electrical Engineer -- NPD/Automation |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | P4H-ICHNDHLD |
| Name of Grantee: | Pentair Aquatic Systems |
| Equipment Class: | Digital Transmission System |
| Notes: | IntelliCenter Wireless Remote Control |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2475.0 | 0.114 |
| Power output is RF conducted. Power output is reduced at band edge channels as addressed in the filing. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedure. Grantee must provide installation and operating instructions for complying with FCC multi-transmitter product procedures and RF Exposure compliance. The highest reported SAR is 0.88 W/kg. |
EAS Grant - Application bi8x4iACzrxeaQTM5r/4aQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Pentair Aquatic Systems 10951 W. Los Angeles Ave. Moorpark, CA 93021 United States |
Date of Grant: 04/18/2017 Application Dated: 04/18/2017 |
| Attention: Edward Feten , Senior Electrical Engineer -- NPD/Automation |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | P4H-ICHNDHLD |
| Name of Grantee: | Pentair Aquatic Systems |
| Equipment Class: | Digital Transmission System |
| Notes: | IntelliCenter Wireless Remote Control |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2475.0 | 0.114 |
| Power output is RF conducted. Power output is reduced at band edge channels as addressed in the filing. The antenna(s) used for this transmitter must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedure. Grantee must provide installation and operating instructions for complying with FCC multi-transmitter product procedures and RF Exposure compliance. The highest reported SAR is 0.88 W/kg. |
