DR9200V Digital Repeater Radio Test Setup... - FCC ID P6NDR-9200V

FCC ID P6NDR-9200V

Test setup

Digital Repeater Radio

by Shenzhen HQT Science&Technology; Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDP6NDR-9200V
Document ID3730401
Document TypeTest Setup Photos
DescriptionTest setup
Document TitleEMC TRF Template
ApplicantShenzhen HQT Science&Technology; Co., Ltd.
Equipment ClassDigital Repeater Radio
Product CodeDR9200V
Application IDkawBYV9qQizTh30RLt0aMQ==
Application PurposeOriginal Equipment
Application Date2018-01-26
Frequency Range136-174 MHz
FRN0021941570
Test FirmShenzhen Huatongwei International Inspection Co.,
Certified ByQian Chen Project Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2018-01-26
Available2018-01-26
Created2018-01-12
Modified2018-01-18
Pages2
File TypeAdobe Acrobat PDF
File Size230950
File SHA-256bb970ebff2966e09802026051451cb6a8648d405b33e34bb4009d01b207c78d2
PDF Metadata Authoreie
PDF Metadata Producereie Microsoft® Word 2010
FCC.gov SourcesFCC.gov 3730401
