0010202 Bluetooth Headset Block Diagram - FCC ID P9P0010202

FCC ID P9P0010202

block diagram

Bluetooth Headset

by ATO Technology Limited

Document preview loads when visible.

Document Details

FCC IDP9P0010202
Document ID273380
Document TypeBlock Diagram
Descriptionblock diagram
ApplicantATO Technology Limited
Equipment ClassBluetooth Headset
Product Code0010202
Application IDctf7c+SX3cbdx7BFmj3a+g==
Application PurposeOriginal Equipment
Application Date2002-09-24
Frequency Range2400-2483.5 MHz
FRN0004265807
Test FirmDEKRA Testing and Certification Co., Ltd.
Certified ByJonathan Lee CTO
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2002-09-27
Available2002-09-24
Created2002-07-01
Modified2002-07-01
Pages1
File TypeAdobe Acrobat PDF
File Size12675
File SHA-2569ff37dcd22bda12edda7003e7a12e63df253dc7de6a35b53d6c0a3c880c2aa24
PDF Metadata ProducerAcrobat 5.0 Scan Plug-in for Windows Acrobat 5.0 Scan Plug-in for Windows
FCC.gov SourcesFCC.gov 273380
