FCC ID PADWF116
GEM 2 Radio Module
by Wahoo Fitness LLC
Grantee Code: PAD Product Code: WF116
Latest application date: 2016-08-03
Device Images
FCC ID Device Details
| FCC ID | PADWF116 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | PAD |
| Product Code | WF116 |
| Applicant Business | Wahoo Fitness LLC 🇺🇸 |
| Related Domains |  wahoofitness.com |
| Equipment Class | GEM 2 Radio Module |
| Test Firm | Shenzhen Anbotek Compliance Laboratory Limited |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-08-03 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-08-03 | PDF 472.2 KB |
| Internal Photos | Internal Photos | 2016-08-03 | PDF 197.8 KB |
| External Photos | External Photos | 2016-08-03 | PDF 165.5 KB |
| Label | ID Label/Location Info | 2016-08-03 | PDF 9.2 KB |
| Label Location | ID Label/Location Info | 2016-08-03 | PDF 610.8 KB |
| RF Test Set-up Photos | Test Setup Photos | 2016-08-03 | PDF 789.4 KB |
| RF Test Report-Ant | Test Report | 2016-08-03 | PDF 1.8 MB |
| RF Test Report-BLE | Test Report | 2016-08-03 | PDF 1.8 MB |
| Authorization Letter | Cover Letter(s) | 2016-08-03 | PDF 22.8 KB |
| LTC Letter | Cover Letter(s) | 2016-08-03 | PDF 24 KB |
| Modular Approval letter | Cover Letter(s) | 2016-08-03 | PDF 48 KB |
| RF Exposure Report | RF Exposure Info | 2016-08-03 | PDF 164.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 134.2 KB | |
| Schematics Metadata only | Schematics | PDF 171.4 KB | |
| Operational Description Metadata only | Operational Description | PDF 11.2 KB |
Application Information
| Application ID | w48SaOys1K18VbewFKHDOg== |
|---|---|
| Final Action Date | 2016-08-03 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0021950779 |
| Model | WF116 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | GEM 2 Radio Module |
| Responsible Party | Julia Donnelly, Technical Project Manager, julia@wahoofitness.com , 8779781112 |
| Test Firm | Daniel zhu, Shenzhen Anbotek Compliance Laboratory Limited, Daniel.zhu@anbotek.com  , 86-755-26014771 |
| TCB Email | tcb@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single modular approval for portable host platform. Power listed is the maximum conducted output power. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| w48SaOys1K18VbewFKHDOg== | 2016-08-03 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0016100 | 15C |
Grants
TCB Grant - Application w48SaOys1K18VbewFKHDOg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 08/03/2016 Application Dated: 08/03/2016 |
| Wahoo Fitness LLC |
| 90 W. Wieuca Road |
| #110 |
| Atlanta, GA 30342 |
| Attention: Julia Donnelly , Technical Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PADWF116 |
| Name of Grantee: | Wahoo Fitness LLC |
| Equipment Class: | Digital Transmission System |
| Notes: | GEM 2 Radio Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.00161 |
| Single modular approval for portable host platform. Power listed is the maximum conducted output power. |
EAS Grant - Application w48SaOys1K18VbewFKHDOg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Wahoo Fitness LLC 90 W. Wieuca Road #110 Atlanta, GA 30342 United States |
Date of Grant: 08/03/2016 Application Dated: 08/03/2016 |
| Attention: Julia Donnelly , Technical Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PADWF116 |
| Name of Grantee: | Wahoo Fitness LLC |
| Equipment Class: | Digital Transmission System |
| Notes: | GEM 2 Radio Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.00161 |
| Single modular approval for portable host platform. Power listed is the maximum conducted output power. |
