TDKA20 Wireless Speaker Teardown Internal Photos - FCC ID PB4-TDKA20

FCC ID PB4-TDKA20

Internal Photos

Wireless Speaker

by Imation Corp.

Document preview loads when visible.

Document Details

FCC IDPB4-TDKA20
Document ID2324924
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleInternal View
ApplicantImation Corp.
Equipment ClassWireless Speaker
Product CodeTDKA20
Application ID9pj1Koam4r6Jope/+2DiOA==
Application PurposeOriginal Equipment
Application Date2014-07-14
Frequency Range2402-2480 MHz
FRN0017631821
Test FirmWaltek Services(Shenzhen) Co., Ltd.
Certified ByPhilo Zhong General Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2014-07-14
Available2014-07-14
Created2014-07-11
Modified2014-07-11
Pages4
File TypeAdobe Acrobat PDF
File Size1058317
File SHA-2564d37b2e257095264d64f38059f8ec89144f4d78e52dde91ea803cfc2b9ddbe83
PDF Metadata Authorlinda.liao
PDF Metadata ProducerAcrobat Distiller 7.0.5 (Windows) linda.liao
FCC.gov SourcesFCC.gov 2324924
